Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator
Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator

Large Image :  Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: ISO, CCC,SGS,BV
Model Number: CLW538J

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: negotiable
Packaging Details: Naked,Waxed,bulk ship,Ro-Ro
Delivery Time: 30-35 days after received deposit
Payment Terms: D/A, D/P, T/T, Western Union, Western Union, L/C
Supply Ability: 500 units/month
Detailed Product Description
Box External Thickness(mm): 1.2mm 1.5mm 1.8mm 2.0mm Internal Thickness(mm): 1.2mm 1.5mm 1.8mm 2.0mm
Interbed Material: Polyurethane Foam Interbed Thickness(mm): 80mm 100mm 120mm
Interior And External Of Box: Fiber Glass,color Steel Drive Model: 4x2/6x4/8x4; As Per Super Structure Size
Wheelbase(mm): 3300mm 3800mm 4500mm 4700mm 5600mm; 4300+1350mm; 1350mm+4300+1350mm Color: White; Blue; Green; Yellow; Customized
Refrigerator Brand: Thermo King,Carrier,Hanxue,Huatai,Bingli Loading Capacity: 5tons,8tons,10tons,15tons,20tons,25tons,30tons,
Truck Brand: FAW,DONGFENG,ISUZU,FOTON,HOWO Freezer Truck
High Light:

6X2 Refrigerated Van Truck

,

Thermo King Refrigerator Refrigerated Van Truck

,

Dongfeng Refrigerated Transport Trucks

6X2 Dongfeng Frozen Lorry Refrigerated Van Truck with Thermo King Refrigerator



Product Description

1. Purpose of Freezer Van Truck ​ : It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.

2. Main parts of Freezer Van Truck ​: Refrigerating unit and control system.

3. Features of Freezer Van Truck ​: International chassis brand and International refrigerating unit brand for optional.

4. For the special requirements of freezer vehicle,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots, ladder, LED lamp, etc. parts can be chosen and installed. Different refrigerated units are available like Carrier, Thermos King, Dongin, Kingtec, etc. The standby battery, side door, side windows, etc are optional.



Freezer truck also called Refrigerated truck, refrigerator truck,refrigerated van truck, refigerated vehicle, freezer truck, cold van, etc.

1. Freezer truck loading capacity :1ton,1.5ton,3ton,5ton,10ton,12ton,15ton,20tons,etc.

2. Freezer truck brand : Foton, 1suzu, Howo, Dongfeng, Jac, Jmc,etc

3. Freezer truck transport : fish, seafood, meat, vegetable, milk, food,fruit, etc.

4.Freezer truck : hot selling in Peru in 2020



Specifications

Vehicle name

Refrigerated

truck

Truck model EQ5250 6x2 Driving
G.V.W(Kg) 25000 Body capacity(m3) 50.5
Load weight(Kg) 15405,15635

Overall dimension

L*W*H(mm)

11100×2550×3990
Curb weight(Kg) 9400,9170 Cargo box size(mm) 8600×2400×2450
Cab passengers 3, with air conditioner
Approach/departure angle(°) 23/11 Suspension front/rear(mm)

1430/1870,1430/2270,

1430/2770,1430/2870

Axle load weight front/rear(Kg) 7000/7000/11000 Top speed(Km/h) 90
Chassis parameters
Chassis model DFH1250BXV Emision standard Euro 2-3-4-5 Optional
Axle number 3 Tire number 8
wheelbase (mm) 1800+4100,1800+5000
Tire size 10.00-20,10.00R20,295/80R22.5
Leaf spring 10/10/10+8,10/10/11+8 Front wheel tread(mm) 1915/1915,1955/1955
Fuel sort diesel Rear wheel tread(mm) 1860
Engine model Engine manufacturer displacement(ml) power(KW/HP)
ISD210 50 Dongfeng 6700 155/210



Reference photos

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 0Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 1

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 2Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 3Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 4

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 5Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 6



Thermo king Independent refrigerator unit MP-4000

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 7



Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 8

Customer Visiting

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 9

Our Service

  • Quick feedback to solve your questions

  • Professional engineering and production team

  • Related Accessories and spare parts offered,no future worries

  • Regular customer after-sale visiting

  • Free technical staff training and guidance

  • Reasonable price and good quality

  • Quick delivery and shipment

Dongfeng 6X2 Refrigerated Van Truck with Thermo King Refrigerator 10

FAQ



Q1: What loading weight freezer truck ​I can order from your company?

A: We can supply 990kg-40tons refrigerated truck, if you need big size refrigerated semi trailer, we also can supply it, there have 2 axles and 3 axles 40tons to 60tons refrigerated semil trailer for optional.



Q2: What is your production standard of freezer truck​? Whether your refrigerated truck and trailer can export to USA, Canada and Europen countries?

A: Our CBU refrigerated truck and trailerg truck is produced as per China GB local standard; We can export super structure to those market, we ever exported refrigerated truck super structure and refrigerated semi trailer to Europen countries before.



Q3: Can we adopts International brand refrigerating unit for freezer truck and semi trailer?

A: Sure, we can supply USA brand Thermo King, Carrier and South Korea brand DONG IN THERMO.



Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.



Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
