| Material: | Carbon Steel, Stainless Steel, Aluminum Alloy | Product Name: | Swing Arm, |
|---|---|---|---|
| Drive Type: | 4X2 6WHEELS 6 WHEELER | Drive Model: | Left Hand Drive, Or Right Hand Drive |
| Loading Capacity: | 8 Tons, 9 Tons, 10 Tons, 5T, 6T. 7T, 8T | Truck Brand: | Dongfeng, Shacman, FAW, FOTON, Jac, Sinotruk HOWO |
| Tuck Type: | Waste Collection Truck. Refuse Truck | Other Equipment: | With Hyraulic Systerm |
| Condition: | Dongfeng Brand, Brand New Truck | Garbage Box: | 8cbm, 10cbm, 8M3, 10M3 |
| High Light: | 10cbm Skip Loader Garbage Truck,170HP Skip Loader Garbage Truck,Skip Loader Container Garbage Truck |
||
Dongfeng 4x2 170hp 10cbm Swing Arm Refuse Truck Roll off Refuse Truck Skip Loader Container Garbage Box Truck
Product Description
Product Description
1. Dongfeng Chassis of waste recycling truck: Engine 170HP, Fast Gearbox 6Forward & 2Reverse;
2. Garbage Bin with different size options of waste recycling truckk: 4cbm to 10cbm;
3. Hydraulic Control Loading&Unloading System;
4. Different shapes of waste recycling truck bins such as trapzoid,boat-shape,square shape and so on and divided into above-ground and under-ground type;
5. High-tensile steel chains:imported hydraulic oil cylinder and sealing material;
6. Lifting oil cylinder:double oil cylinder under garbage box,so garbage box can be lifted and self-dumped;
7. Double rear landing leg controlled by hydraulic multi-way valve to stablise truck;
8. Best Choice for Garbage collection and transporation Inside City.
product Specification
| General Technical Parameters | |||
| Overall Dimension | 7370X2470X3330 (mm) | ||
| Gross Vehicle Weight | 12490(Kg) | ||
| Curb Weight | 6295(Kg) | ||
| Chassis Specification | |||
| Chassis Brand | Dongfeng145 | ||
| Drive model | 4*2 | ||
| Cabin | Single Row, LHD, with air condition. | ||
| Number of Passengers | 3 | ||
| Engine | Model | B170-33/170HP, 4-stroke direct injection , 6-cylinder in-line, turbocharged intercooled, withABS. | |
| Power | 125KW/170HP | ||
| Emission standard | EURO 3 | ||
| Displacement | 5900(ml) | ||
| Fuel type | Diesel | ||
| Gearbox | Fast 8JS85E, 6Forwards & 2Reverse, manual operation, with power steering. | ||
| Brake System | Oil break | ||
| Wheel Base | 3950mm | ||
| Front/Rear Axle Loading | 4990/7500(Kg) | ||
| Approach/Departure Angle | 30/21(°) | ||
| Overhang | Mechanical Suspension, 9/11+8 | ||
| Tire | 9.00-20, 6pc with 1 spare tire | ||
| Max Driving Speed | 90(km/h) | ||
| Upperstructure Specification | ||
| Garbage Hopper | Dimension | 3700×1850×1400mm |
| Standard Configuration | With one garbage bin, with hydraulic rear outrigger | |
| Volume | Ground type, 8CBM | |
| Loading Capacity | 6Ton | |
| Thickness | 5mm, Carbon Steel Q235B | |
| Dump type | Hydraulic cylinder lifting and self-loading | |
| Dump angle | ≥45° | |
| Hydraulic system pressure | ≤16Mpa | |
| Protective Material | Q235A Carbon Steel | |
| Controlling Way | Three-way hydraulic control valve | |
| Other Configuration |
|
|
| Options | Electronically controlled valve, trash bin type, trash bin quantity, etc. | |
Dongfeng 4x2 170hp 10cbm Swing Arm Refuse Truck Roll off Refuse Truck Skip Loader Container Garbage Box Truck
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
FAQ
Q: Can I buy a sample of your product for testing?
A. Yes, that's fine. Our MOQ is 1set.
Q: What's about the payment?
A: 40% deposit by T/T before order,balanced by T/T before delivery.
Q: How about quality of your factory product ?
A: Our product quality is ahead of other manufacturers in the industry. We have advanced production equipment ,skilled workers and perfect mangement quality. So the quality is under control. Our products are certificated by ISO 9001:2008,CCC and BV, and many trucks passed SGS inspection .
Q: How do you gurantee the quality of the product?
A: Don't worry, my dear client. Any one of you is very important to us. So we will do inspect all of the goods before shipment. And we had joined the trade credit insurance system. If the product received has quality problems, Alibaba will return the advance payment back to you.
Q: Why do you choose us?
A: We are self-produced and self-selling manufacturer and we have more than 15 years of production experience, our products have been sold all over the world.
Q: What about your after-sale service?
A: We offer 1 year after-sale service. We can supply the spare parts at factory price all the time.
Q: Can we visit your factory before purchasing?
A: We welcome you to visit our factory any time and we will show you our production line .
