SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane
SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane

Large Image :  SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: CCC, ISO, BV, SGS
Model Number: CLW5140

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: Negotiable
Packaging Details: Naked Pack with Wax
Delivery Time: 30-35 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Units/Month
Detailed Product Description
Chassis Brand: HOWO,Dongfeng, Foton, Isuzu Etc. Container Volume: 20cbm, Optional From 5m3 To 20m3
Loading Capacity: 15ton,16ton, 17ton, 18ton, 19ton, 20tons Box Thickness: Side 4mm, Bottom 5mm, Carbon Steel Q235B
Protective Material: Q235A Carbon Steel Dump Type: Hydraulic Cylinder Lifting And Self-loading
Controlling Way: Three-way Hydraulic Control Valve Usage: Domestic Garbage Transportation
Color: As Per Customer's Request LOGO: As Per Customer's Request
Warranty: 1 Year Operating Video: Yes
User Manual: Yes
High Light:

LHD Hooklift Garbage Truck

,

8x4 Hooklift Garbage Truck

,

HOWO Hooklift Garbage Collection Truck

SINOTRUK HOWO 8X4 LHD hydraulic hooklift garbage truck with 18m3 Garbage Container with 5tons folded arm crane

Description:

A hooklift truck is a heavy-duty truck chassis that's been fitted with a hydraulic hooklift hoist. The hydraulic hoist system lets contractors, municipalities and other work vehicle users roll on and roll off different truck bodies or containers. ... Roll on a dump container.


It is widely used in collection and transit garbage which come from cities, towns, rural areas, large factories and mining enterprises and living areas of colleges and universities.



We can produce many kinds of garbage trucks, including compactor garbage truck, garbge collection truck, garbage transportion truck, container garbage truck, hydraulic lifter garbage truck, self-loading garbage truck, skip garbage truck, arm-roll rubbish truck, hanging bin garbage truck, dump garbage truck, hermetic garbage truck, sealed garbage trucks for sale, arm shaking garbage truck, and so on.

1. Chassis: Sinotruk howo, dongfeng, isuzu, faw, jac, shacman, camc and so on

2. Garbage Bin with different size options of hook lift garbage truck : 4cbm to 12cbm; Engine 266hp,290hp,336hp,371hp, Fast Gearbox 6Forward & 2Reverse

3. Hydraulic Control Loading & Unloading System

4. Different shapes of hook lift garbage truck bins such as trapzoid,boat-shape,square shape and so on and divided into above-ground and under-ground type
5. High-tensile steel chains:imported hydraulic oil cylinder and sealing material

6. Lifting oil cylinder of hook lift garbage truck :double oil cylinder under garbage box,so garbage box can be lifted and self-dumped

7. Double rear landing leg controlled by hydraulic multi-way valve to stablise truck

8. Best Choice for Garbage collection and transporation Inside City



Currently we produce the garbage compactor truck from 4 ~ 18 m3.
Skip swing arm container garbage truck from 4~10 m3.
Hooklift garbage truck from 3~20 m3.
Sealed dump garbage truck from 3 ~10 m3.

Product Specifications

Vehicle Name HOWO 8x4 hooklift garbage truck
Brand Sinotruck Howo
Engine Power &
Transmission
Engine Model WD619.69
Engine Brand Sinotruck Engine Co., Ltd
Fuel Type Diesel
Displacement / Power 9726ml / 247kw, 336HP
Chassis Chassis Type ZZ1317N326GF1
Dimension (LxWxH)(mm) 9800 x 2496 x 2920
Chassis Weight(kg) 9150
Wheelbase (mm) 1800+3050+1350
Drive Type 8X4
No. of Axles 4
Cab seats 3 + 1 berth
Max Speed(km/h) 80
Tire 12.00R20 18PR, 315/80R22.5
Tire No.'s 12+1 spare
Track width F/R (mm) 2015/2015/1830/1830
Chassis load (kg) 6500/7000/17500
Front/Rear suspension 1430/2250
Appr/Dep Angle (°) 19/17
Weight & Dimension
(With van box)
Gross Vehicle Weight(kg) 31000
Curb Weight(kg) 18360
Rated Weight / load(kg) 12510
Upper structure-
Arm Roll
Hook arm Made of Q235B high quality carbon stell
Hydraulic oil cylinder 2 sets, hydraulic oil cylinder
Pulling & Lifting Force(T) 26-30
System Working Pressure (Mpa) 27.5
Rail Width(mm) ≥1060 mm
Hooking Time(s) ≤75
Discharge Time(s) ≤75
Self-Unloading Angle(°) ≥49
Other details Folded arm crane capacity 5Tons


Reference Photos

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 0

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 1

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 2



Main Structure and Diagram
SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 3





SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 4
Factory overview

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 5

SINOTRUK HOWO 8x4 LHD Hydraulic Hooklift Garbage Truck With Folded Arm Crane 6



Sales Service


1) Pre-sales Service: Communicate with customers, analyze their needs.
2) Sales Service: Provide professional technical solutions, recommend the right models accordingly.
3) After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.


FAQ



Q1: What kinds of garbage truck I can order from your company?

A: We can supply different sizes of garbage truck as client's request. As for the capacity, we can supply 5CBM to 20CBM type. Pls contact with us for more technical details and discussion.

Q2: What is your production standard of garbage Truck?
A: China GB local standard.

Q3: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q4: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to Wuhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!





Warranty



1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer manual, video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.



Spare Parts



1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.



Shipment



Land transportation or Ship by bulk cargo ship, container, roro ship
