Product Details:
Payment & Shipping Terms:
|
| Size Option: | 30m3,40m3,50m3,60m3,70m3,80m3,100m3,120m3 | Materail: | Carbon Steel Q345R |
|---|---|---|---|
| Filling Medium: | Propane,butane | Tank Diameter: | DN2200mm |
| Design Pressure:: | 1.77Mpa | Production Standard: | GB150 |
| Test Pressure: | 2.28Mpa | Level Gauge: | China Brand Megnatic Type Or US Brand Rocheseter |
| Tank Valves: | Cut-off Valve, Needle Valve, Safety Valve, Return Valve Etc.. | Corrosion Allowance: | 1 Mm |
| Service Time: | 15 Years | LOGO: | As Per Request |
| High Light: | 15 Tons LPG Gas Storage Tank,30000 Liters LPG Gas Storage Tank,30000 Liters Liquid Propane Gas Tank |
||
15tons LPG Gas Storage Tank 30,000Liters Propane Gas Tanker for Gas Filling Plant
Product Description
1. Storage medium of lpg gas plant tank : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
2. Tank sizes:5,000L, 20,000L, 30,000L, 40,000L, 50,000L, 60,000L, 80,000L, 100,000L, 120,000L etc.
3. Manufacturing standards of lpg gas plant tank : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008
4. Tank basic accessories included: valves, level meter, thermometer, pressure gauge etc.
5. Optional for lpg gas plant equipments as follows, lpg pump and motor,lpg compressor,volume flow meter,filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.
6. Maintenance-free operation with simple calibration and proof testing.
7. 20 years guarantee against manufacturing defects.
| Parameter of 30000liters 15tons LPG Gas Storage Tank | ||||||
| ITEM | PARAMETER | ITEM | PARAMETER | |||
| Volume | 30cbm | Thickness of Shell | 12mm | |||
| Tank Material | Q345R | Thickness of End plate | 14mm | |||
| Overall Size | 8158*2324*2914mm | Tank Net Weight | 7110kg | |||
| Tank Diameter | 2700mm | Loading Capacity | 12768kg | |||
| Design Pressure | 1.77Mpa | Gas Density | 420kg/M3 | |||
| Hydraulic Test Pressure | 2.22Mpa | Corrosion Allowance | 1mm | |||
| Design Temperature | -20ºC~60ºC | Heat Treatment | Bulk | |||
| Vapor Outlet | DN50 | Gas Outlet | DN50 | |||
| Life time | 15 years | |||||
| Accessories | ||||||
| Model | Item | Qty | Junction surface | |||
| J41N-2.5-50 | Stop Valve DN50 | 6 | RF | |||
| J41N-2.5-25 | Stop Valve DN25 | 2 | RF | |||
| J41N-2.5-100 | Stop Valve DN100 | 1 | RF | |||
| J24W-320-DN6 | J24W Needle Valve M20*1.5 | 1 | ||||
| HG21584-95 | Magnetic plate level Gauge UZFAL-2.5RF-3040-0.5 | 1 | RF | |||
| A42F-25-100 | Safety Valve DN100 | 1 | RF | |||
| Y-100T | Pressure Gauge M20*1.5 1.5degree 0~4Mpa | 1 | ||||
| WTQ-280 | Thermometer M33*2 2.5 degree | 1 | -40ºC~60ºC | |||
LPG filling station design
