Payment & Shipping Terms:
|Brand:||Dongfeng,Sinotruk,Foton,Isuzu,Faw,Shacaman||Drive Mode:||4*2 4*4 6*2 8*4, Etc. As Per Cusomer Request.|
|Tank Material:||Q235B And Stainless Steel For Optional||Tank Size:||5CBM; 8CBM; 10CBM; 12CBM; 15CBM|
|Tank Capacity:||5t; 8t; 10t; 12t; 15t||Tank Thickness:||4mm; 5mm; 6mm|
|Water Pump Flow:||20m³/h||Water Diversion Time:||<15min|
|Sprayer Dimension:||1100*500*1700mm||Water Cannon Range:||30m|
|Water Consumption:||0.8—1 M3/h||Water Suction Depth:||7m|
|Water Sprinkle Width:||15m||Logo And Painting:||As Per Customer's Requests|
|Delivery Time:||30-35 Working Days||Warranty:||1 Year|
Foton Water Bowser Truck,
4x4 Water Bowser Truck,
Foton Water Sprinkler Truck
1. Optional chassis brand: Dongfeng, Sinotruk, Foton, Faw, Shacaman, Isuzu;
2. Water Tank Material: High Tension Steel Q235/Q345,stainless steel 304B for option.
3. Reliable and high quality water pump
4. Optional for insulation layer which is suitable for warm water delivery.
|General Technical Parameters|
|Gross Vehicle Weight||8280(Kg)|
|Cabin||Single, Left Hand Driving|
|Number of Passengers||3 (2 in cabin, 1 in working platform)|
|Engine||Model||4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling|
|Emission standard||EURO 2or 3|
|Gearbox||5Forwards & 1Reverse|
|Brake System||Air break|
|Front/Rear Axle Loading||2700/5000(Kg)|
|Tire||8.25R20, 6pcs + 1 spare tire|
|Max Driving Speed||90(km/h)|
|Material||Q235B carbon steel|
|Thickness of Tanker||4mm|
|Water Pump Material||carbon steel|
|Range of Water Gun||30m|
|Range of Water Pump||90m|
|Other Configuration||High quality vacuum pump, power take off, ball valves, filter screen, water hoses, sprinkler device, manhole, fense&ladder, vice-beams, anti-wave clapboard, metering tube, etc.|
|Options||Caution light, inlet valve, medicine tray, pneumatic valve, cylinder, sprayer, etc.|
1. Provide English operation manual and Instruction videos.
2. One year free warranty for major 3 components: engine, gearbox, axles; One set of easily worn spare parts of truck chassis for free; Spare parts supplied at factory price whenever needed.
3. Aftersales service whenever needed. Our engineers will go to customer's country to assist the installation and operation if order QTY.is more than 10 units. Flora+86 13971508969.
Q1: What kinds of water bowser I can order from your company?
A: There are various sizes and types of water bowsers with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2: Have you supplied water bowsers to any overseas companies?
A: Yes,with need of government and construction project,we offered water bowsers to many Africa and south-east Asian,south-American countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q4: Where is your factory? How far from Shanghai to your factory?
A: Our factory is based in Suizhou city, Hubei province, China. Our overseas marketing office is in Wuhan city,Hubei Province.Wuhan is about two hours' plane and four hours' high speed train from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
Contact Person: Ms. Flora
