Product Details:
Payment & Shipping Terms:
|
| Brand: | ISUZU,Dongfeng,FOTON, HOWO, JAC, JMC, SHACMAN,FAW | Material: | Carbon Steel |
|---|---|---|---|
| Thickness: | Side 3 Mm And Bottom 4 Mm | Wheel Base: | 3308mm |
| Horsepower: | 120HP, ISUZU | Hydraulic Pump: | Chinese Famous Brand |
| Control System: | Siemens Brand Operate System. | Warranty: | 1 Year |
| Drive Wheel: | 4x2, 4x4, 6x4, 8x4,others | Fuel Type: | Diesel, Electric |
| Hand Driving: | LHD Or Rhd |
Product Description
1--Truck chassis : Howo,Foton,Dongfeng,Faw,Shacman,JAC,JMC,ISUZU etc.
2--Garbage container size from 4cbm to 22cbm.
3--Easy operation from cabin or rear side of truck, button control panel & opeartion handle
4--Highly efficient compression system which makes waste management more easy.
| 6cbm Garbage Compactor Truck Waste Collection Truck | |||
| Overall Dimension | 8280×2850×2350 mm | Gross Vehicle Weight | 8280 kg |
| Curb Weight | 2580 kg | Loading Weight | 5995 kg |
| Wheel Base | 3308 mm | Front / Rear Axle | 3300/4980 kg |
| Cabin | Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio, | ||
| Engine | DONGFENG brand | ||
| Engine horsepower | 120HP, EURO IV | ||
| Max Driving Speed | 90 km/h | ||
| Gear Box | 5 Forward Gear, 1 Reverse Gear, | ||
| Tire | 6.50-16 6 pieces with one spare) | ||
| Garbage Bin | Capacity | 7cbm or 8CBM | |
| Material | 4mm Carbon Steel for Garbage Bin Body | ||
| Design | Whole unit with Leakage Proof Design | ||
| Ways of Loading | Rear Loading with optional Bucket Lifting System | ||
| Garbage Compact Ratio | 1/3 - 1/4 | ||
| Control System | One control Panel on the back, One Control system in back of Cabin | ||
| Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. | ||
| 2. Automatic loading, compressing and discharging, all handled by 1 person | |||
| 3. Sewage water collection tank to avoid any pollution during handling. | |||
| 4. Large Pressure, Good Leakage Proof, Convenient Operation | |||
| Dependable Security | |||
| 5. Electrical Control Panel for compacting system. | |||
| 6. Cycling time<14~18s | |||
| Remarks | 1. Color is optional | ||
| 2. Customized LOGO painting as per customer request | |||
