Product Details:
Payment & Shipping Terms:
|
| Box Material: | Carbon Steel Q235B | Truck Brand: | SINOTRUK HOWO, DONGFENG, FAW, FOTON, ISUZU |
|---|---|---|---|
| Tank Volume: | 5cbm/5000Liters | Truck Engine: | Customized |
| Gearbox: | Fast 8 Forward & 1 Reverse | Tire: | 7.00R16(6 Pieces With One Spare) |
| Axle: | 5Ton Front Axle & 10Ton*2 Rear Axle | Garbage Truck Type: | Compactor |
| Color: | Customized |
HOWO 5m3 Sanitation Self- Compressed 3tons Garbage Compactor Truck
Product Description
Product Specifictions
| ITEM | UNIT | PARAMETER | ||
| Vehicle | HOWO 4X2 Garbage compactor truck | |||
| Overall dimensions | mm | 7000×2280×2680 | ||
| Tank volume | m3 | 5 | ||
| GVW | kg | 7360 | ||
| Curb weight | 5400 | |||
| Payload | 1830 | |||
| Wheel base | mm | 3360/3800 | ||
| Suspension | 1250/2610 | |||
| F/R track base | 1940/1860 | |||
| Cabin | Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio, | |||
| Max speed | km/h | 90 | ||
| Front / Rear Axle | kg | 5000 / 10000 | ||
| Tire specification | 7.00R16 (6 pieces with one spare) | Number of axles | 2 | |
| Engine horsepower | 116HP, EURO III | Diesel, 6 Cylinder, direct line, water cooling | ||
| Ways of Loading | Rear Loading with optional Bucket Lifting System | |||
| Steering | Power | Garbage Compact Ratio | 1/3 - 1/4 | |
| Cab passenger | 2 | Electric System | 24V | |
| Tank material | Carbon steel | |||
| Standard configuration |
1. Hydraulic system powered by trucks chassis PTO 2. Body with rear lifting system to handle garbage containers capacity 120L, 240L. 3. Body sides and roof built from high tensile sheets thickness 5mm. 4. Box platform built with high tensile sheets thickness 4 mm, hopper floor built with high tensile sheets thickness 5 mm. 5. Body painted 1 coat anti-corrosion primer and 2 coats synthetic paint |
|||
Reference photos
Truck diagram
Main parts
Factory overview
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer manual, video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
FAQ
Q1: What kinds of garbage trucks I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2: Have you supplied garbage truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
