| Brand: | ISUZU,HOWO,ISUZU,Dongfeng,FOTON, JAC, JMC, SHACMAN,FAW | Material: | High Intense Carbon Steel, Q235 |
|---|---|---|---|
| Thickness: | Side 3 Mm And Bottom 4 Mm | Wheel Base: | 3360mm |
| Horsepower: | 120HP, ISUZU | Hydraulic Pump: | Chinese Famous Brand |
| Control System: | Siemens Brand Operate System. | Warranty: | 1 Year |
| Operation Video: | Yes |
Product Description
Refuse compactor truck is designed to increase the amount of garbage carried per circle, reduce the collection period and to provide flexibility to its operators. We provide different types of production according to customer's requirement.
Truck chassis: HOWO,Dongfeng,FOTON,Shacman,FAW,JAC,JMC,ISUZU,CAMC.
Garbage bin capacity: 5cbm,8cbm, 10cbm, 12cbm, 14cbm,16cbm, 18cbm, 20cbm, 22cbm.
Easy PLC control system: Cabin operation control & rear part panel for easy operation
Multi-type Rear Loader design: Flip bucket, sealing large container, swing arm container, pebnumatic sealing cover, Tri-angle container.
Spefications of refuse compactor truck
| 5cbm Refuse Compactor Truck | |||
| Overall Dimension | 7300*2350*2570 mm | Gross Vehicle Weight | 8495 kg |
| Curb Weight | 5080 kg | Loading Weight | 3400 kg |
| Wheel Base | 3360 mm | Front / Rear Axle | 2500/3500 kg |
| Cabin | Left Hand Driving, 2 Passengers Allowed, with Air Conditioner, Radio, | ||
| Engine | ISUZU brand | ||
| Engine horsepower | 130HP, EURO V | ||
| Max Driving Speed | 90 km/h | ||
| Gear Box | 5 Forward Gear, 1 Reverse Gear, | ||
| Tire | 7.00R16, 6 pieces with one spare) | ||
| Garbage Bin | Capacity | 5CBM | |
| Material | 4mm Carbon Steel for Garbage Bin Body | ||
| Design | Whole unit with Leakage Proof Design | ||
| Ways of Loading | Rear Loading with optional Bucket Lifting System | ||
| Garbage Compact Ratio | 0.6 - 0.8 | ||
| Control System | One control Panel on the back, One Control system in back of Cabin | ||
| Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. | ||
| 2. Automatic loading, compressing and discharging, all handled by 1 person | |||
| 3. Sewage water collection tank to avoid any pollution during handling. | |||
| 4. Large Pressure, Good Leakage Proof, Convenient Operation | |||
| Dependable Security | |||
| 5. Electrical Control Panel for compacting system. | |||
| 6. Cycling time<14~18s | |||
| Remarks | 1. Color is optional | ||
| 2. Customized LOGO painting as per customer request | |||
Waste Compactor Truck Production Process
Customized design as per customer's request
Professional engineer team with 20 years experience
Production photos and video, easy see the whole process
Test before shipment, customer can do live inspection
Operation video to teach you how to use the truck step by step
Spare parts whenever needed at factory price, freight cost by customer's side
Maintenance gudiance whenever need
One year warranty and life long service
