Product Details:
Payment & Shipping Terms:
|
| Brand: | HOWO,FAW,ISUZU,Dongfeng,FOTON, JAC, JMC, SHACMAN | Material: | High Intense Carbon Steel,Q235 |
|---|---|---|---|
| Thickness: | Side 3mm And Bottom 4 Mm | Garbage Bin Size: | 5cbm,5m3 |
| Wheel Base: | 3360mm | Horsepower: | 98HP, Euro5 |
| Hydraulic Pump: | Chinese Famous Brand | Control System: | Siemens Brand Operate System. |
| Warranty: | 1 Year | Logo: | Customized Painting And Logo |
| Operation Video: | Yes | Shipment: | Bulk Shipping Or Roll Roll |
| Controlling Way: | Manual And Electrical Control | Campacting Ratio: | 0.75tonnes/cbm |
| Dirty Water Tank Volume: | 0.26cbm | Hopper Volume: | 0.73cbm |
| High Light: | Driving Type 5cbm Rear Loader,ISUZU 4x2 Rear Loader,5cbm Hanging Bucket Sanitation Management Truck |
||
1. Hydraulic system, including the control valve, oil cylinder, connecting pipeline and other key parts, has advanced structure, reliable performance, simple operation and convenient maintenance.
2. Advanced electric control system :
3. Back pressure valve, which can highly improve the loading efficiency.
4. The beautiful streamlined appearance design, high-strength anti-corrosion steel plate
5. Double Operation System: electrical control system and manual operation greatly improves the vehicle usage rate.
6. Electric and hydraulic control, improves the reliability of the vehicle.
7. Automatic control of engine power output:
The engine power output control
Meet the power requirements of the garbage filling cycle and pushing and unloading.
Reduce power loss and accident rate, reduce fuel consumption and improve economical use.
8.Frame structure:
Beautiful appearance, light weight, good force and no deformation:
Light in structure, but also makes the garbage evenly distributed, and the discharge is clean and thorough;
Each component adopts the beam plate or box structure with good stress , The structure is firm and the weight is light.
| Isuzu rear loader garbage truck | ||
| General | Chassis Brand | ISUZU |
| Overall Dimension | 5995×2000×2450mm | |
| GVW / Curb Weight | 4495kg / 4140kg | |
| Cab | Capacity | 2 persons allowed |
| Air Conditioner | Heating&cooling air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Type | 4KH1CN5LS | |
| Power | 98HP | |
| Emission Standard | Euro5 | |
| Chassis | Drive Type | 4X2, (Left hand drive) oil break |
| Gear box | 5 speed levers with 1 reverse | |
| Wheelbase/No. of axle | 3360mm / 2 | |
| Tire Specification | 700R16 radial tire | |
| Tire Number | 6 tires with 1 spare tire | |
| Max Speed | 85 km/h | |
| Paint | Metallic paint | |
| Superstructure | Body capacity | 5CBM |
| Fill Hopper capacity | 0.73cbm | |
| Sewage tank | 600 liters | |
| Filling work cycle time | 20~25 s | |
| Discharge model | Horizontal Ejection | |
| Control system | Electrically hydraulic control Manual hydraulic control |
|
| Control panel | English or Your language | |
| All standard accessories: Dust bin lifter,Ladder, warning lights, Emergency stop button, handrail, fire extinguisher, basic tool kit, English manual... |
||
| Optional |
1) Back alarm and Camera can be equipped. |
|
1.Beautiful and strong box structure
2. PC control operation panel and hydraulic rear flip mechanism
Production Process:
Successful cases:
Our Product advantages:
1. Garbage Compactor Truck change the dirty appearance of the city and eliminate the secondary pollution.
2. It is equipped with computer control system for loading and unloading operations.
3. One Person operate that can reduce sanitation working time and greatly improves the working environment.
4. It install computer control system and manual operation system in order to improve the vehicle using rate.
