Product Details:
Payment & Shipping Terms:
|
| Truck Chassis: | ISUZU,HOWO,Dongfeng,FAW,JAC,JMC,FOTON | Material: | Carbon Steel Q235A |
|---|---|---|---|
| Thickness: | Side 4mm, Buttom 4mm | Fuel: | Diesel Type |
| Water Pump: | China Famous Brand | Suction Height: | 7 M |
| Cannon Range: | 30 M | Sprinkling Width: | 15 M |
| Operation Video: | Yes | User Manual: | Yes |
| Logo: | As Customer's Request | Warranty: | 1 Year |
| Water Tank Truck Type: | Water Spraying Tank Truck | ||
| High Light: | 13000 Liters Water Sprinkler Truck,Sanitation Water Bowser Truck |
||
Optional chassis brand: Dongfeng, Sinotruk, FOTON, Forland, Faw, Shacaman.
water transportation, road sprinkling, plant watering.
Q235 water tank, front, side and rear sprinkler nozzle.
antiskid platform with water cannon.
The water cannon can rotate 360 degree and the water flow can be adjusted to mist, light rain, moderate rain, heavy rain.
The spraying width of chengli water tank truck is more than 15m and the cannon range is more than 25m.
Reliable and high quality water pump
Instructions for use of the vehicle:
When the sprinkler uses rivers and ponds as water sources, pay attention to the fact that all the ends of the suction pipes are submerged in the water.
In order to avoid inhalation of stones or more sediment and debris, a filter device is installed at the suction port of the suction pipe.
If the water source is shallow, it is necessary to dig deeper into the water absorption area in advance to ensure that it does not contain debris and does not enter the air.
When the self-priming pump is used for the first time, it is necessary to add water diversion, and it is not necessary to add water diversion later.
When absorbing water, the water inlet pipe system must maintain a certain degree of vacuum in order to suck the water into the tank.
The water inlet pipe system must be sealed and reliable, the hose must not be damaged, and the hard pipe must not have cracks, otherwise there will be air leakage, which will cause the situation that water cannot be absorbed.
Whether the sprinkler truck is absorbing water or before sprinkling water, the power take-off device must be in gear when it is parked.
Before winter comes, the water in the water pump and water pipe should be emptied to prevent freezing and cracking.
Generally, construction is not carried out in the severe winter in the north. Therefore, after the construction is completed, the water in the water pump and water pipe should be drained immediately to prevent future troubles.
| Items | Descriptions | Specifications and Types | |
| General | Truck Name | 13000L Water Bowser Truck | |
| Drive Type | 4*2 | ||
| Gross Weight(kg) | 16000 | ||
| Curb Weight (kg) | 7050 | ||
| Approx.Overall Dimensions (mm) | 7700×2496×2958 | ||
| Engine | Engine Model | WD615.87 | |
| Engine Brand | Cummins | ||
| Fuel Type | Diesel | ||
| Power | 190HP | ||
| Emission Standard | Euro V | ||
| Displacement(ml) | 6440 | ||
| Engine Type | 6 cylinders in line, inter cooler, supercharged diesel engine | ||
| Chassis | Chassis Brand | Dongfeng | |
| Cabin | One row with single sleeper, titled, flat roof,with ac | ||
| Tire No. | 6+1 | ||
| Tire Specification | 11.00R20 All Steel tire | ||
| Axle No. | 2 | ||
| Steering Wheel | Left hand drive with power-assisted | ||
| Gear Box | FAST 8 speed forward with 1 reverse, manual | ||
| Brake | Air brake | ||
| Tank | Tank Volume(L) | 13000 | |
| Tank Shape | Rectangular | ||
| Tank Material | Carbon Steel, 5mm thick | ||
| Performance | Spraying Width(m) | 14 | |
| Canon Range(m) | 25 | ||
| Equipment |
1.Front flushing , side spraying, rear sprinkling nozzle and platform with water cannon and water gun. 2.The water cannon can be rotated 360 degree. The water flow can be adjusted to heavy, medium, light rain, drizzle and mist. 3.Water suction depth is about 7m. |
||
1. Water Truck Digram
2. Truck details:
2.Main structure:
Front flush nozzle at the bottom of the cab
The rear of the tank is equipped with an anti-aircraft gun workbench
Forged manhole
Tank Side Tool Box
3.Working Diagram
4.Production Line for Water Tank Truck
Sales Service
①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
