Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck

Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck
Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck

Large Image :  Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: CCC,ISO,BV,SGS
Model Number: CLW50749

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: negotiable
Packaging Details: Naked packing
Delivery Time: 30-35days after received advance payments
Payment Terms: T/T, L/C
Supply Ability: 300 units per month
Detailed Product Description
Material: Stainless Steel 304 Auxiliary Engine: ISUZU Brand
Fan: Maintenance Free Rear Warning Light: Yes
Vacuum Suction: Behind The Tire Brushes: 4 Units
Usage: City Sanitation Color: Customized LOGO Painting As Per Customer Request
High Light:

street sweeper vacuum truck

,

mechanical sweeper truck

Dongfeng Mini Road Sweeper Truck 2.5m3 Street Vacuum Cleaner Truck





Product Description



This equipment is made from our company according to many years of road maintenance construction experience, and combined with the actual needs of customers.It is a kind of vacuuming equipment independently developed and produced for minor repair and maintenance construction of irrigation joints and pits.The utility model has the characteristics of simple operation, high dust absorption efficiency and continuous operation.Widely used in municipal, highway, national and provincial arterial road construction dust, particle recovery operations.



Specifications of 2.5CBM Changan Road Sweeper Truck



2CBM Road Sweeper Truck
Condition New condition/Right hand drive/4x2
Chassis Brand Changan
Curb weight(kg) 2300kg
Wheelbase(mm) 2600 mm
Dimensions(mm) 4650 x 1750 x 2250 mm
Overhang (front/rear) (mm) 1032 / 1868
Wheel track (front/rear) (mm) 1506 / 1404
Approach/Departure angle(°) 19/12
Axle Load(kg) 1500/2000
Max. driving speed(km/h) 90 km/h
Tire Specifications 6pcs with one spare tire
Number 165R14
Clutch Reinforced diaphragm clutch
Gear box Manual type, 5 Forwards & 1 Reverse
Cabin Left Hand Driving, 2 Passenger Allowed, with A/C
Engine Model Diesel Engine, 4 Cylinders
Power(kw)/Horsepower(HP) 65 kw/88 HP
Emission standard Euro 3
Brakes

Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Steering Gear Power steering, hydraulic steering with power assistance
Sweeping System
Tank Garbage tank Tank material Stainless steel 304
Tank volume(cbm) 2 CBM
Water tank Tank material Stainless steel 304
Tank volume(cbm) 0.5 CBM
Auxiliary engine Model ISUZU Engine 77HP
Power(kw) 28 kw
Brush Quantity(pc) 4 pcs
Working area(m) 2.7-2.8 m
Remarks

1, With water sprayer-bar

2, Rear vacuum cleaner

3, Blower

4, Rear LED pilot lamp

5, Self unloading box body

6, The color will be designed on basis of your requirements.


Details

Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck 0

Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck 1

Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck 2

Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck 3Dongfeng Mini Road Sweeper Truck 4 Units Brushes Street Vacuum Cleaner Truck 4



Sales Service



① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.





FAQ



Q1: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.



Q2: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
