Product Details:
Payment & Shipping Terms:
|
| Type: | Telescopic Type Aerial Lift Truck | Bucket Capacity: | 200kg |
|---|---|---|---|
| Bucket Size: | 1000x700x1250mm | Working Arm Type: | H Type |
| Max Operation Height: | 18meters ~ 22meters | Max Operation Range: | 8meters ~9meters |
| Chassis Brand: | Dongfeng, ISUZU, Etc | Engine Brand: | ISUZU, Cummins |
| Warranty: | 1 Year | ||
| High Light: | Telescopic Aerial Platform Truck,JMC Aerial Platform Truck,21M Aerial Lift Truck |
||
21Meters JMC Straight Arm Telescopic Aerial Platform Truck for Streets light Bridge Maintenace
Product Show
Product Details
| ISUZU Aerial Platform Truck | |
| Overall dimensions | 8450×2050×3100 mm |
| Wheel base | 3800 mm |
| F/R track base | 1015/2280mm |
| Approach/departure angle | 24/10° |
| Front / Rear Axle | 2Ton / 4.8Ton |
| Cabin | ISUZU 600P cabin, Double Row, Left Hand Driving, with A/C, Radio |
| Engine | 4KHF-TCG40, Diesel type, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling, Euro IV |
| Displacement/ HP | 2999ml / 120hp |
| Gearbox | ISUZU 5 foward &1 reverse |
| Steering Gear | Hydraulic Power Steering |
| Max speed | 90 km/h |
| Tire specification | 7.00-16, 6 Pieces |
| Traction system | 4x2 |
| Superstructure main technical Parameters | ||
| Max operation height | 21m(= Working bucket’s Max height above ground+ Industry unified standard human height 1.7m) | |
| Boom | Working booms type | Three folded arms |
| Boom’s max lift angle | 65° | |
| Hydraulic system | Hydraulic pump | Gear pump |
| Hydraulic system pressure | ≤16Mpa | |
| Hydraulic tank volume | 80L | |
| Working bucket | Max height above ground | 18.3(m) |
| Max operation range | 8.7(m) | |
| Operation range at min operation height | 3.07(m) | |
| Operation range at max operation height | 11.5(m) | |
| Working bucket slewing angle | 360° | |
| Rated load | 200kg | |
| outrigger | Outrigger Type | H type |
| Numbers of outrigger | 4 | |
| Horizontal span | 2930(mm) | |
| Longitudinal span | 4500(mm) | |
| Hook | Max lift weight | 800(kg) |
| Max lift height | 8.5(m) | |
| Operation | Control method | Manual control |
| Outrigger control | Horizontal / vertical individually adjustable | |
| Operating position | Working bucket, on the truck or under the truck | |
Sales Service
①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
FAQ
Q1: What kinds of truck mounted aeriel platform I can order from your company?
A: There are various sizes and types of arerial platform trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied truck mounted aeriel platform to any overseas companies?
A: Yes,with need of government project,we offered aerial platform trucks to many Africa and south-east Asian countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
