90km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

90km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  90km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: CCC,ISO,SGS,BV
Model Number: CLW5120ET

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: Naked Pack with Wax
Delivery Time: 20-30 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 600Unit Per Month
Detailed Product Description
Brand: HOWO,Dongfeng,JAC,JMC,forland,foton Passenger: 2~3 Person
Engine: Yunnei Brand/Chinese Top Brand Front Leg: H Shape
Rear Leg: H Type Height: 14Meters,16meters, 20meters, 22meters
Bucket Capacity: 200kg Boom Type: Three Section Knuckle Arm
Delivery Time: 30 Days Warranty: 1 Year
Logo: As Per Customer's Request User Manual: Yes
Operation Video: Yes Truck Purpose: Street Light Repair
High Light:

14 Meter Cherry Picker Truck

,

SINOTRUK HOWO Cherry Picker Truck

,

90km/h aerial work platform truck

SINOTRUK HOWO 14 meters Cherry Picker Truck Man Lift Platform Working Truck

Product Description

1. Electronical controlled Lifting Arm with Doulbe Side Balance Vavle.
2. Four Hydraulic Cylinders Control Leg to ensure the Truck Balance.
3. 360 degree Rotation Arms.
4. Arm and H leg Automatic Locking System to secure safety handling.



Parameter Overall dimension (Length*width*high) (mm) 7400×2000×3100
00Total Mass (kg) 5775
Kerb Mass (kg) 5450
Wheel base (mm) 4175
Front/rear tract base (mm) 1385/1425
Approach/rear angle   27/11
Max speed (km/h) 90
Fuel type   diesel
Engine Engine type   Yunnei
Displacement standard   EURO 3
Chassis Chassis type   HOWO
Drive system   4x2
Tire type   7.00R16
Number of tire   6
Front/rear axle loading(kg)   1015/2025
passengers
Cabin   Single, with 2 passengers allowed, with Air conditioner
Special parameter Working platform rating loading (kg) 200
Working Height (m) 14
Max working radius (m) 6.46
Boom type   three section knuckle arm
Max hook height (m) 7.2
Loading of hook (kg) 800-1000
Max rotation angle (°) 360



Reference photos

90km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck 090km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck 190km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck 2





Diagram for cherry picker truck



90km/h SINOTRUK HOWO 14 Meter Cherry Picker Truck 3
