Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck
Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck

Large Image :  Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck

Product Details:

Place of Origin: China
Brand Name: CLW
Certification: ISO, CCC
Model Number: CLW5658

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: USD27500-38500
Packaging Details: Naked packing
Delivery Time: 30-35days after received advance payments
Payment Terms: L/C, T/T
Supply Ability: 500units/month
Detailed Product Description
Tank Material: Strong Carbon Steel Tank Capacity: 15CBM To 20CBM
Pump: Italian Jurop, Weilong Brand Truck Brand: Dongfeng, Sinotruk, Shacman, Benz,
Tank Pressure: -0.97Mpa Optional: 60meter Rubber For Sewer Cleaning
Tire: 11R22.5, 12R22.5. 10 Pieces With 1 Spare Tire Loading Capacity: 15Ton To 20Ton
Color: Customized
High Light:

6x4 20T Vacuum Sewage Suction Truck

,

Dongfeng Kinland Vacuum Sewage Suction Truck

,

Dongfeng Kinland Septic Tank Truck

Dongfeng Kinland 6x4 20000 Liters 20tons Vacuum Sewage Suction and high pressure cleaning truck septic tank truck


Description:

1. Chassis:
1)
Drive type: 4x2, 4x4, 6x4, 8x4 etc.
2) Our factory has good business relationship with
DONGFENG, FOTON, ISUZU, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
2. Tanker body:From 2m3 to 25 m3 capacity.
3. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.

Specifications:

Item Descriptions Spesifications and Types
Vehicle Brand Dongfeng
Overall Dimensions L*W*H 9590*2500*3800mm
Weights GVW. 25000kgs
Curb Weight 13005kgs
Rated Payload 11800kgs
Chassis Chassis Brand Dongfeng Kinland
Drive Type 6x4
Steering LHD
Engine Brand Dongfeng engine
Power 180Kw /245HP
Emmission Level EURO V or VI
Performance Max. Speed 90km/h
Wheel base 4350+1350mm
Tyre Specifications 10.00-20,10.00R20,11.00-20,11.00R20
No. of Tyre 10 pcs (1 spare tyre included)
Cab Cab Capacity 2 persons allowed
Body/Superstructure Tank Capacity 20 M³/20000Liters/ 20tons
Material 5mm or 6mm high quality carbon steel
Vacuum pump China famous vacuum pump
Vacuum rate 99% thorically
Suction head 6m
Rotation speed 500 rpm,low noise,high efficiency
Basic
Equipments

Install vacuum pumps and hydraulic systems driven by engine through

PTO. One multi-way valve, pressure gauges, water-gas separator, oil-gas separator, hydraulic oil tank, a level inspection window, hand

washing tank and a piece of 6m suction hose

Paint Tank color is according to client's requirements.
Optional Equipments Italy or Spain vacuum pumps
Stainless steel
Anti-rust coating inside tank



Reference photos

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 0Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 1Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 2

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 3

Working shop

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 4

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 5



Factory overview

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 6

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 7

The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.

Products Catalog:

1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor truck
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

Dongfeng Kinland 6x4 20T Vacuum Sewage Suction Truck 8



Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.



FAQ

Q1: What kinds of Sewer cleaning truck I can order from your company?

A: We can supply normal sewege suction truck and high pressure sewer flushing and sewage suction truck, the difference between those two kinds of sewer cleaning truck are water tank and high pressure water pump. Basically speaking, we can supply 5CBM to 35CBM sewer cleaning truck as per our customer's request. Pls contact with us for more technical details discussion.



Q2: What is your production standard of Mobile Advertisement Truck products? Whether your Mobile Advertisement Truck can export to USA, Canada and Europen countries?

A: Our CBU Sewer cleaning truck is produced as per China GB local standard; We can export super structure to those market, we ever exported 50 units sewage suction truck's super structure and 20 units sewage suction sewage trailer to Australia market in the past two years.



Q3: Can we adopts International brand sewage pump for sewage suction truck?

A: Sure, we already cooperated with Italy Jourp and a Germany brand.



Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.



Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!



Warranty



1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.



Spare Parts



1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
