HOWO 140 Horse Power Mobile Gas Filling LPG Distribution Truck 15m3 With Flowmeter

Large Image : HOWO 140 Horse Power Mobile Gas Filling LPG Distribution Truck 15m3 With Flowmeter

Product Details:

Place of Origin:	SUIZHOU,CHINA
Brand Name:	CLW
Certification:	ASME,CCC,BV,SGS
Model Number:	CLW57YD9S

Payment & Shipping Terms:

Minimum Order Quantity:	1 Unit
Price:	negotiable
Packaging Details:	naked,waxed,bulk ship,ro-ro
Delivery Time:	30 days after receiving advanced deposit
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability:	500 units/month

Contact Now

Detailed Product Description

Truck's Brand:	Sinotruk HOWO,ISUZU,Dongfeng,Shacman,FAW,JAC,JMC	Engine:	YC4E140-42 YUCAI
Design Pressure:	1.61 Mpa	Tank Material:	Q345R
Tank Volume:	15000Liters,15cbm,15m3	Loading Weight:	7tons, 7mt,8tons,8mt
Flow Meter:	Displacement Flow Meter	Pump:	Hydraulic Pump With PTO Powered
Discharging Valve:	1", 2", 3"Flange Type	Service Time:	10 Years
Warranty:	One Year For Engine, Gearbox, Axle	Logo& Painting:	Customized
Usage:	Cylinder Refilling, Truck Gas Supply
Highlight:	HOWO 140HP LPG Distribution Truck , 15m3 LPG Distribution Truck

HOWO 140 Horse Power 15m3 Mobile Gas Filling Truck LPG Distribution Truck With Flowmeter

Product Description

LPG bobtail truck capacity: from 5cbm to 37.2cbm
tank meaterial:Q345R Q370R Q420R SA516
tank production flow:cuttings-bending plate-submerged arc welding-assembly-non destructive testing-heat treatment- hydraulic test- sand blasting-painting
Refiling System of LPG Bobtail Trucks : 2" Flowmeter or intelligent filling dispenser machine,2" Corken or Chinese brand Pump,15meters Filling Hose Reel,filling nozzle,radiator,hydraulic oil box
Truck Spec of LPG Bobtail Trucks : Yucai diesel Engine 140hp, with ABS XH-KQ4S4M-E01,8.25R20,9.00R20 tires.

Specification

Condition	New Condition / LHD
Chassis	Brand	SINOTRUK HOWO
	Curb Weight(kgs)	4155
	G.V.W.(kgs)	12490
	Wheel Base(mm)	4700
	Dimensions(mm)	819523302550
	Voerhang(Front/Rear)(mm)	1240/2255
	Approach/departure Angle	27/19
	Max driving speed	95
	Tire	6 pcs with one spare tire 9.00R20
Clutch	Reinforced diaphragm Clutch
Engine	Model	YUCAI
	Fuel type	Diesel
	Displacement(ml)	4260
	Power(kw)	103
	Horsepower(hp)	140
	Cylinder Number	6
	Emission Standard	Euro 4
Cab	3 Passenger Allowed , With A/C
Steering Gear	Power steering , Hydraulic steering with power assistance
Tank Parameter	Tank material	Carbon Steel Q345R
	Loading capacity(cbm)	15cbm(15000 liters)
	Tank sharp	Double Ellipse
	Thickness of shell(mm)	10
	Thickness of End Plate(mm)	12
	Filling Medium	Liquefied Petroleum Gas(Propane)
	Corrosion Allowance(mm)	1
	Filling Ratio	0.42
	Design Pressure(Mpa)	1.61Mpa
Safty accessory parts :Safety valve , Cut-off valve , thermometer, Liquid level gauge , Pressure Gauge
