HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm

HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm
HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm

Large Image :  HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm

Product Details:

Place of Origin: Suizhou, China
Brand Name: CLW /Weiyu Brand
Certification: CCC, ISO
Model Number: CLW5251GXWD5

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: negotiable
Packaging Details: Nude Pack with Waxing
Delivery Time: 10-20 Work Days
Supply Ability: 500 units/month
Detailed Product Description
Tank Capacity: 18000L Tank Material: Carbon Steel
Material Thickness: 5mm To 6mm Tank Shape: Cylinder Shape
Tipping System: Hydraulic Tipping Pump Brand: BP, Jurop , Moro Italian Brand
Pump Type: Wind Or Water Cool Vacuum: 93% ~ 97%
High Light:

Vacuum Waste Collection Tanker

,

HOWO Sewer Suction Waste Collection Tanker

,

16cbm Vacuum Suction Truck

HOWO 16cbm Sewer Suction Vacuum Waste Collection Tanker



1. Tandem axles vacuum trucks (water or vacuum trucks) are designed to fit on an under 10ton GVW chassis.
2. Tanks are built using high strength steel with dished and flange tank heads.
3. Our finish process includes both inside and outside epoxy coatings. Epoxy interior paint inside the tank will extend the life of your investment.
4. Exterior baked on enamel, including metallic and base-coat clear cote options will ensure that your truck image will match the quality of the work you do.


Product Features:

CLW GROUP offers a full range of vacuum tanks used in the industrial plants, oil and gas industry, and sewage/septic markets.
Our industrial vacuum tanks install to a burden carrier of pull behind cart/trailer, used to vacuum out oil pits, paint pits, and other functions in large industrial plants.
The oil and gas industry utilize the vacuum tanks as water tanks, hauling frak water from frak sites to disposal sites. We also offer a full range of tanks to haul drip gas or chemicals
Septic/Sewage trucks can be built to fit your chassis.
We offer Jurop vacuum pumps.
Atestainless steel tank construction, and custom sizes are a few of the available options.



HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 0


Vehicle Description
Overall dimensions 9800*2500*3700mm
GVW 25000kg
Mass in working order 12800kg
Chassis brand HOWO
Traction type 6*4
Tanker Description
Tanker Capacity 16000L
Material 6mm thickness, high quality carbon steel
Structure Welding, vacuum tank, Cylindrical
Pump Type Double vacuum pump
Flux 68(L/S)
Rating speed 800~1000(r/min)
Shaft power 5(kw)
Features Low speed, low fuel consumption, low noise, high vacuum, high efficiency
Manufacture Hangzhou WEILONG Pump Co., Ltd.
Pipe Suction and discharge pipe
Special function Suction time ≤ 5mins,
effective suction range ≥ 8,
Max vacuum degree ≤ 15 Kpa,
dump angle ≥ 45
Standard configuration Equipped with Inspect window,discharge valve,cleaning apparatus,5 meter long suction pipe,oil-water separators, overflow valve,etc.
Cylinder vacuum tank can be lifted hydraulically to
40-45 degree. Rear door can be opened and closed hydraulically.
Optional configuration Tanker material: stainless steel.
Vacuum pump : Italy or Spain vacuum pumps.
Anti-rust coating inside tank
Chassis Description
Chassis model SINOTRUK HOWO
Cab Sleeper cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension, adjustable driver's seat, air conditioning system, electric windows, central lock.
Traction type LHD
Drive type 6x4
Wheelbase 4325+1350mm
Tire specification 12.00R20
Tire quantity 10+1 units
Engine Engine model WEICHAI
Emission level Euro 2
Displacement/output 9726ml
Horse power 336hp
Gear box Model HW19710
Number of gears 10 forward gears & 2 reverse, synchronized
Brake system Full air brake system, split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake
Axle Front 9T- Elliot type, I beam section
Rear 16T*2-Single reduction, ratio 5.143
Suspension Front 8/8- Leaf spring with shock absorber
Rear 9/9-Leaf spring
Fuel tanker Type Steel fuel tank, with lockable cap
Capacity 350L







HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 1


HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 2


HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 3

HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 4



HOWO Sewer Suction Vacuum Waste Collection Tanker 16cbm 5







Sales Service



①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.





FAQ



Q1: What kinds of sewer vacuum truck I can order from your company?

A: We can supply normal sewege suction truck and high pressure sewer flushing and sewage suction truck, the difference between those two kinds of sewer cleaning truck are water tank and high pressure water pump. Basically speaking, we can supply 5CBM to 35CBM sewer cleaning truck as per our customer's request. Pls contact with us for more technical details discussion.



Q2: What is your production standard of sewer vacuum truck? Whether your sewer vacuum truck can export to USA, Canada and Europen countries?

A: Our CBU sewer vacuum truck is produced as per China GB local standard; We can export super structure to those market, we ever exported 50 units sewage suction truck's super structure and 20 units sewage suction sewage trailer to Australia market in the past two years.



Q3: Can we adopts International brand sewage pump for sewage suction truck?

A: Sure, we already cooperated with Italy Jourp and a Germany brand.



Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.



Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
