Sinotruk HOWO NX 40m³ LPG Dispenser Truck with Corrosion-Resistant Components and 400HP Diesel Engine for Bulk Propane Distribution

Large Image : Sinotruk HOWO NX 40m³ LPG Dispenser Truck with Corrosion-Resistant Components and 400HP Diesel Engine for Bulk Propane Distribution

Product Details:

Place of Origin:	Suizhou, China
Brand Name:	CLW
Certification:	CCC,ISO,
Model Number:	clwfdsgdrh

Payment & Shipping Terms:

Minimum Order Quantity:	1 UNIT
Price:	Negotiable
Packaging Details:	Naked packing,Ro-ro,Bulk Ship
Delivery Time:	20-30 Days
Payment Terms:	L/C,T/T,D/P,D/A,Western Union,,MoneyGram
Supply Ability:	500Unit Per Month

Contact Now

Detailed Product Description

Highlight:

40m³ Capacity LPG Dispenser Truck

Corrosion-Resistant Components LPG Gas Tanker Truck

400HP Diesel Engine Propane Delivery Truck

Sinotruk HOWO NX 40m³ LPG Dispenser Truck

The Sinotruk HOWO NX 40m³ LPG dispenser truck (20MT capacity) is a premium-grade propane and butane delivery solution designed for both long-haul transportation and mobile refueling services. This bobtail truck ensures safe LPG supply to industrial zones, residential distribution centers, and roadside fuel points across West Africa.

Key Features for West African Market

High-Volume LPG Hauling & Dispensing
Tank capacity: 40,000 liters (40m³)
Working pressure: 1.61 MPa
USA Corken 2" vane pump with 15-meter hose reel
High flow rate suitable for bulk cylinder filling and station refueling

Multi-Level Safety & Durability Structure
National pressure vessel approval with high-strength Q345R steel
Triple-banded air tanks and collision-resistant rear bumper
Battery anti-theft device and safety valve protection
FRP step plates for slip prevention

Strong Powertrain for Heavy-Duty Service
Weichai WP12S400E201 Euro-2 diesel engine - 400HP
HW19710 10-speed manual transmission
Reliable performance in mountainous roads and long-distance haulage

Tailored Configuration for African Environment
Sun visor for high UV exposure
Stainless steel toolboxes to resist corrosion
Fully enclosed valve and meter compartments with rolling shutters
Fire extinguishers and static grounding reel equipped as standard

Technical Specifications

Truck Chassis
Overall Dimensions	12000×2510×3845mm (L×W×H)
GVW	31000kg
Curb Weight	21000kg
Cab	Sinotruk HOWO NX, Left hand drive, 2 or 3 seats, One sleeper, Heating and Cooling AC
Engine	Weichai 400HP, Euro 2, 6 Cylinder in Line, Water Cooling, Four Stroke, Direct Injection
Gearbox	Manual transmission, 10 forward and 2 reverse gear
Axle Loading	Front axle 9500kg/9500kg, Rear axle 16000kg/16000kg
Tire	315/80R22.5, 12+1 pcs
LPG Tanker
Tank Capacity	40m³ (20MT)
Filling Medium	Liquefied petroleum gas (LPG)
Tank Material	Q345R, Tanker body 12mm, End plate 12mm
Design Pressure	1.61MPa
Corrosion Allowance	1mm
Stress Relief	Heat treatment
Hydraulic Test Pressure	2.1MPa
LPG Pump	USA CORKEN 2"
Additional Features	Valve box at rear, Chinese brand Level Gauge, Pressure Gauge, Thermometer, Volume Flow Meter in Liters, Liquid phase and Vapour phase with Rego connector and Rego cap, 15m filling hose and Rego filling gun
