61.9 CBM LPG Gas Tanker Trailer with Q345R Steel Construction and 1.61 MPa Working Pressure

Name: 61.9 CBM LPG Gas Tanker Trailer with Q345R Steel Construction and 1.61 MPa Working Pressure
Brand: HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
Price: 44,935.00 USD
Availability: InStock

Large Image : 61.9 CBM LPG Gas Tanker Trailer with Q345R Steel Construction and 1.61 MPa Working Pressure

Product Details:

Contact Now

Detailed Product Description

Highlight:

61.9 CBM LPG Gas Tanker Trailer

Q345R Steel Construction LPG Gas Tanker Trailer

1.61 MPa Working Pressure LPG Gas Tanker Trailer

30mt 61.9cbm Propane Gas Tanker Trailer

61.9 CBM LPG Semi-Trailer - Built for Safety, Strength, and High-Efficiency Transport Our 61.9 CBM LPG Semi-Trailer is purpose-built to handle the demanding requirements of liquefied petroleum gas transportation. With a strong emphasis on safety compliance, long-term durability, and smooth operation, it delivers reliable performance for large-scale LPG logistics.

Tank Structure & Safety Standards

Large Volume Capacity - Featuring a 61.9 CBM tank volume and a maximum gross weight of 41,000 kg, this trailer is designed to optimize payload capacity and transport efficiency.
High-Strength Steel Construction - The tank shell is manufactured from 12 mm Q345R pressure vessel steel, paired with 14 mm elliptical heads for enhanced strength. A 1.0 mm corrosion allowance and a 100% weld joint efficiency ensure long service life and structural reliability.
Certified Pressure Performance - Engineered to safely transport LPG, the tank operates at a working pressure of 1.61 MPa (16.1 bar) and undergoes pressure testing at 2.12 MPa (21.2 bar) to meet stringent safety requirements.

High-Efficiency Loading & Unloading System

Powerful LPG Pump - Equipped with a USA-made CORKEN Z2000 vane pump driven by a hydraulic motor, enabling fast and stable unloading operations.
Precision Flow Measurement - A Coriolis mass flow meter provides accurate flow monitoring, supporting precise quantity control and reliable commercial transactions.
Complete Transfer Accessories - Supplied with a 15-meter LPG hose, REGO filling nozzle, and standard liquid and vapor phase interfaces for broad compatibility with filling stations.

Safety Devices & Monitoring System

Real-Time Status Monitoring - Includes a Rochester float-type level gauge, pressure gauge, and temperature indicator for continuous monitoring of tank conditions.
Emergency Protection System - Features both a manual emergency shut-off device and a truck-mounted emergency braking button for immediate response in critical situations.
Anti-Static & Overpressure Protection - Integrated safety valves and an electrostatic grounding system effectively reduce operational risks during LPG handling.

Chassis & Running Gear Configuration

Heavy-Duty Axles - Outfitted with three FUWA axles, each rated at 13 tons, providing excellent load support and driving stability.
Reliable Coupling & Suspension - Uses a JOST kingpin combined with a mechanical leaf spring suspension system for dependable performance under long-distance operations.
Standard Accessories - Comes complete with 12R22.5 tires (12 units plus one spare), fenders, spare tire carriers, sunshade, and a DN450 manhole for convenient inspection and maintenance.

Surface Treatment & Customization

The trailer is finished with a high-quality anti-corrosion primer and topcoat, ready for branding with your company logo and colors.

This 61.9 CBM LPG Semi-Trailer is a dependable, high-capacity solution for LPG transport operators seeking safety, efficiency, and long-term value in their fleet.

Technical Specifications

Overall Technical Parameters	Specifications
Capacity of Tank	61.9 CBM
Overall Dimensions (LWH)	1335025503995mm
Curb Weight (kg)	15000
Total Weight (kg)	41000
Loading medium	Liquefied Petroleum Gas (propane & butane)
Fluid Property	Flammable
Design Temperature	-19 ℃ ~ +50 ℃
Design Working Pressure	1.61 MPa / 16.1 Bar
Hydraulic Testing Pressure	2.12 MPa / 21.2 Bar
Corrosion Allowance (mm)	1
Weld Joint Factor	1
Materials and Thickness	Tanker Body: Q345R, 12mm End plate: Q345R, 14mm, Elliptical Baffles: Q345R

Upper Structure	Specifications
Filling system	LPG Vane Pump: USA brand CORKEN Z2000 & Hydraulic Motor Vapour & Liquid Phase: Threaded type with Rego connector and cap Flow Meter: Chinese brand Coriolis Mass Flow Meter Filling Hose: 15 meters long rubber hose Filling Gun: 1pcs, Rego brand Level Gauge: Rochester floating ball level gauge Pressure Gauge x1 Thermometer x1
Safety Equipment	Emergency Shut-off Handle Truck Emergency Brake Button Safety Valves

Running System	Specifications
Axles	13T FUWA Axles x 3 units
Suspension	Mechanical suspension with leaf spring
King-pin and Coupling	JOST king-pin
Tire	12R22.5, 12+1 pcs

Other Details	Specifications
Sun shelter	On top of the tanker
Manhole	1 pc, DN450
Fire Extinguisher holder	2 pcs
Fender	2 pcs
Tire Carrier	2 pcs
Electrostatic conduction band	1 pc
Painting and Logo	Two coats of primer, one coat of surface painting Customized color of tanker body with client's logo
