Isuzu KV100 30m Height Aerial Work Truck with 6-section Polygonal Boom and 200kg Platform Capacity

Name: Isuzu KV100 30m Height Aerial Work Truck with 6-section Polygonal Boom and 200kg Platform Capacity
Brand: HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
Price: 19,885.00 USD
Availability: InStock

Large Image : Isuzu KV100 30m Height Aerial Work Truck with 6-section Polygonal Boom and 200kg Platform Capacity

Product Details:

Contact Now

Detailed Product Description

Highlight:

30m Height Aerial Work Truck

6-section Polygonal Boom Bucket Truck

200kg Platform Capacity Manlift Truck

ISUZU KV100 30m Truck Mounted Aerial Platform

Introducing the Isuzu KV100 30m Aerial Work Truck — the perfect fusion of Japanese engineering reliability and high-performance aerial technology. Need to work at 30 meters high or reach 24 meters sideways? This bucket truck delivers rock-solid stability, a spacious work platform, and the legendary comfort of the KV100 cabin. Get the job done safely, efficiently, and in style.

Overview

Imagine driving to the job site in the comfort of an Isuzu KV100—air conditioning, power windows, and effortless steering. Then, with the touch of a control, extend the 6-section polygonal boom 30 meters into the air. That's the experience of our 30m manlift truck. Unlike standard units, the 14-sided boom design minimizes wobble, giving your crew the confidence to work precisely. With outriggers that spread wide to 6.4 meters, this machine feels like solid ground, even at full height.

Key Features

Isuzu Reliability: Built on the proven Isuzu KV100 chassis (130HP, Turbo Diesel, National VI). It's a truck you can trust to start every time and run all day.
Massive Working Range: Up to 30m height, 24m lateral reach, and 28m backward reach for unmatched versatility
"V" Shape Outriggers: Front V and Rear V hydraulic leg setup provides a super-wide 6.4m stance for maximum stability
Spacious Platform: Large 3.2m long steel basket (3200x700x1100mm) with 200kg maximum load capacity
Customization Options: Dual oil-electric operation, reverse camera, hydraulic winch, and upper operation cab

Applications

Tree care and complex tree removals
Electrical contractors and overhead line work
Facility management and high-level maintenance
Signage installation and billboard placement

Technical Specifications

Vehicle Parameters	Specifications
External Dimensions	766524303780mm (length, width, height)
Total Mass	12000kg
Curb Weight	11605kg
Emission Standard	National VI
Wheelbase	3815mm
Tire Specification	275/80R22.5 16PR
Engine Model	4KB1-TCG60
Displacement	2499ml
Power	96kW (130HP)
Boom Structure	6-section 14-sided large arm, synchronous telescopic
Outrigger Spread	6400mm horizontal, 6100mm vertical
Platform Size	3200(1800)7001100mm (length, width, height)
Platform Load Capacity	200kg
Maximum Working Height	35m
Lateral Extension	24m
Backward Extension	28m
