5T 6T 8T 2000 Gallons 8000L Milk Transport Truck

small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  5T 6T 8T 2000 Gallons 8000L Milk Transport Truck

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: CCC BV SGS
Model Number: CLW5287STWD

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: 11250-29560USD/UNIT
Packaging Details: Naked package shipped by bulk ship
Delivery Time: 30 days after receiving deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Units/Month
Detailed Product Description
Capacity: 5ton 5t 6ton 6t 8ton 8t Tank Material: Stainless Steel Q304-2B
Insulation Layer: 80mm PU Foaming Out Tank Material: 2mm Q304L
Internal Tank Material: 4mm 304-2B Engine: Diesel,120hp
Steering: LHD,RHD Tank Volume: 5cbm,5000liters,6000liters,6cbm,8cbm,8000liters
Product Name: Milk Tanke Truck,milk Delivery Truck,milk Transport Truck
High Light:

6T Milk Transport Truck


8T Milk Transport Truck


8000L Milk Delivery Truck

Fresh Milk Transport Tanker Truck 5Tons~8Tons,8000L 2000 Gallons Drinking Water Milk Delivery Truck




Fresh milk transporter(also called milk tanker, milk transporter, milk preservation transporter, liquid food transporter truck) is  mainly used to transport fresh goat milk, fresh milk, fresh juice, edible oil,Fresh-keeping edible products such as bulk beer. With excellent heat preservation and anti-corrosion effects,milk transport truck can ensure that the product is stored in the tank for 24 hours and the temperature is within the range of plus and minus 1 degrees Celsius.



►Feature1. The tank body is made of 4mm 304-2B food-grade stainless steel clean surface bright cold steel plate material,which is completed by argon arc welding process, the welding is smoother and the welding is splash-free, which is beneficial to cleaning;

2. The tank body is made by the design process of independent and separate compartments and is divided into
compartments according to customer requirements. Each compartment is equipped with a self-flowing port to make the tank body more rigid, not easy to deform and increase service life;

3. Each
compartment is equipped with cip internal automatic cleaning device to ensure that 2.2 meters is equipped with 2 automatic cleaning balls to ensure that the tank has a 360-degree cleaning effect without dead ends;

4. The thermal insulation layer adopts the polyurethane integral foaming process, the foaming thickness is 80-120mm.The temperature difference within the tank body within 24 hours under normal temperature conditions is less than 1 degree;

5. The outer layer of polyurethane foaming process is wrapped with 10mm rubber sponge, which further improves the insulation performance of the tank, and increases the flame retardancy and shock resistance of the tank;

6. The outsourcing is made of 2mm304 stainless steel plate, the appearance is stainless steel and the overall appearance is beautiful and atmospheric;

7. Mechanically sealed manhole cover equipped with an automatic breathing valve, which automatically adjusts the positive and negative pressure difference formed between the inside and outside of the tank during driving, which makes driving safer;

8. Tank body adopts the design process of high front and low rear, which promotes the fresh milk to flow more cleanly and quickly;

9. The tank body adopts a three-layer design process. The first layer of the inner tank is made of 4mm304-2B food-grade stainless steel sheet, which is polished and polished inside to achieve a smooth and clean inside of the tank body without acute angles; the second layer is a 80-120mm polyurethane foam insulation layer ; The foaming layer is wrapped with 10mm rubber sponge to further improve the insulation performance of the tank; the third layer uses a 2mm stainless steel outsourcing process to ensure driving safety; the tank can be divided into warehouses and open warehouses, according to customer requirements. Types of products are transported at one time, each silo body is equipped with cip (automatic cleaning device): cleaning rod or cleaning ball, multiple automatic rotating cleaning nozzles, with automatic discharge port, cleaning pipe, and inlet tank port;

10. optional for chillers, flow meters, level gauges, safety locks, leak-proof devices, rock wool insulation, etc.


►Reference pictures

5T 6T 8T 2000 Gallons 8000L Milk Transport Truck 05T 6T 8T 2000 Gallons 8000L Milk Transport Truck 1

►Stainless cleaning inlet and outlet of milk

5T 6T 8T 2000 Gallons 8000L Milk Transport Truck 2

5T 6T 8T 2000 Gallons 8000L Milk Transport Truck 3


Cab Left hand drive
Chassis Brand Dongfeng
Drive type 4x2
Tire Spec. 7.50-16
Tire Numbers 6
Transmission manual
Engine Model CY4102-C3F
Horse Power(hp) 95
Displacement(cc)/ Power(kw) 3856/75
Emission Euro 3
Main Parameters Overall dimension (L*W*H/mm) 5995x2000x2400
Wheelbase(mm) 3300
Axles No. 2
GVW(kg) 6495
Curb Weight(kg) 3365
Rated Payload(kg) 3000
Approaching/Departure Angle(°) 19/10
Front/Rear track(mm) 1506/1466
Front/Rear suspension(mm) 1032/1663
Max speed(km/h) 90
Tank Tank Volume(L) 5000
Tank Material Stainless 304
Tank thickness(mm) Internal 4mm
External 2mm
Insulation thickness(mm) 80mm
Equipment 1) PIC cleaning device inside of the tank

2) Tank Structure: 4mm stainless steel inner tanker , 80mm insulating layer

and 2mm stainless steel shell plating.

3) Food grade pipe system and discharge valve, SMS food grade butterfly valve.


Our Service

  • Quick feedback to solve your questions

  • Professional engineering and production team

  • Related Accessories and spare parts offered,no future worries

  • Regular customer after-sale visiting

  • Free technical staff training and guidance

  • Reasonable price and good quality

  • Quick delivery and shipment




Q1: What kinds of milk delivery truck I can order from your company?

A: We can supply various sizes of milk trucks such as 2ton,3ton,4ton,5ton,6ton to 25ton, if you need larger size, there are 2 axles and 3 axles semil trailer for optional.


Q2: What is your production standard of milk delivery truck? Whether your milk delivery truck or trailers export to USA, Canada and Europen countries?

A: Our milk delivery truck is produced as per China GB local standard; We can export super structure to those market, we ever exported milk delivery truck super structure to Europen countries before.


Q3: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.


Q4: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
