50m³ Bulk Feed Semi-trailer with Hydraulic Auger System and Carbon Steel Construction

Large Image : 50m³ Bulk Feed Semi-trailer with Hydraulic Auger System and Carbon Steel Construction

Product Details:

Place of Origin:	CHINA
Brand Name:	CLW GROUP
Certification:	ISO
Model Number:	semi-trailer

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	20600
Packaging Details:	Rain shelter fabric packaging
Delivery Time:	30DAYS
Payment Terms:	T/T
Supply Ability:	10pcs/month

Contact Now

Detailed Product Description

Material:	Carbon Steel

50cbm 3-Axle Bulk Feed Semi-trailer with Hydraulic Auger System

50m³ Auger Feed Trailer for Poultry & Livestock Farms - Gentle Particle Handling

Hubei Weiyu Special Vehicles offers a full range of tri-axle bulk feed transport solutions to meet diverse logistics needs. Whether you need a compact 50m³ model for regional distribution, a versatile 59m³ model for balanced performance, or a heavy-duty 65m³ model for long-haul bulk transport, we have you covered.

All models feature a new U-shaped tank,整板一次成型 technology, and high-efficiency auger unloading system. With affordable prices and reliable quality, our trailers are the first choice for feed mills and breeding farms worldwide.

General Specifications

Available Length: 10m / 11m / 12.6m
Available Volume: 50 m³ / 59 m³ / 65 m³
Core Configuration: FUWA Axles, Siemens Motors, Remote Control Auger
Tire: 12R22.5 12PR
Leaf Spring: -/8/8/8, -4/4/4
Key Feature: 360° Rotatable Auger, No Residue Discharge

Detailed Specifications

Item	Specification
Overall Dimension	11000×2550×3999 mm
Axle	3 Axles (Fuwa)
Volume	65 m³
Tare Weight	9.2 T
Wheelbase	4950+1310+1310 mm
Leaf Spring	-/8/8/8, -/4/4/4
Tire	12R22.5 12PR (Chaoyang)
Kingpin Front Distance	1500 mm
Kingpin Plate Height	1300 mm
Turning Radius	1965 mm (Front), 2260 mm (Clearance)
Kingpin to Rear	9500 mm
Unloading	Remote Control Auger, Optional 360° Rotation
Control	LCD (Remote + Manual)
Top Cover	Pneumatic Sliding Cover
Motor	Siemens
Tank	U-Type, One-Piece Bent Steel

Product Gallery

Key Advantage: Advanced hydraulic auger system with 360° rotation capability ensures gentle handling of feed particles and complete discharge with no residue remaining.
