Product Details:
Payment & Shipping Terms:
|
Tanker Material: | Stainless Steel, Aluminum Alloy | Drive Type: | 4x4 AWD, Off Road For Bad Road Condition |
---|---|---|---|
Drive Model: | Left Hand Drive, Or Right Hand Drive, RHD | Tank Volume: | 12000L, 15000L, 12CBM, 15CBM, 12M3, 15M3 |
Truck Brand: | Dongfeng /Sinotruk HOWO, Shacman, FAW, FOTON, Jac | Tuck Type: | Aviation Kerosene, Jet A1 Transport, Delivery And Refilling |
Other Equipment: | Charging/discharging Valves. API Manhole | Compartment: | 1 |
Dispenser: | With Dispensers ( 2 Fuel Filling Machine) | Product Name: | Helicopter Aircraft Aviation Rufueling/Refilling Filling Tank Truck |
Type: | For Army, Military Using | Transmission Type: | Manual |
High Light: | 5Cbm Fuel Delivery Truck,HOWO 4x4 Fuel Delivery Truck |
Product Description
1. Purpose: It used for helicopter refueling and mobile transporting aviation kerosene.
2. Main parts: Fuel pump, flow meter and filling gun etc.
3. Advantage: Our helicopter refueling truck have most competitive price.
Truck Chassis Main Specification
(1) Sinotruk HOWO Flat Cabin, With one or Without Sleeper Bed. Air conditioner.
(2) Diesel Engine, 266 HP, EURO-2, or Euro-3, EURO-4.
(3) Steering Wheel: RHD/LHD
(4) Drive Model: 4x4 Full Wheel Drive/Off Road For Bad Road Condition.
(5) Transmission/Gearbox, Manual control
(6) Front Axle:3 ton,Rear Axle: 5Ton
(7) Fuel Tanker: 300L
Condition | New condition/Left hand drive | ||
Drive Type |
4x4, Full Wheel Drive, All Wheel Drive, AWD. Off Road Type For Army, Military Using |
||
Chassis | Brand | SINOTRUK | |
Model | HOWO | ||
Curb weight(kg)(Whole Truck) | 4700 kg | ||
Loading weight(kg) | 3700 kg | ||
Wheelbase(mm) | 3800 mm | ||
Front/Rear axle loading weight(kg) | 6000/10,000 kg | ||
Dimensions(mm)(Whole Truck) | 6500×2600×2400 mm | ||
Front/Rear overhang(mm) | 1500/2675 mm | ||
Approach/Departure angle(°) | 20/14° | ||
Max. driving speed(km/h) | 80 km/h | ||
Clutch | Reinforced diaphragm clutch | ||
Brakes | Service brake: dual circuit compressed air brake. Parking brake:(emergency brake): spring energy, compressed air operating on rear wheel. Auxiliary brake: engine exhaust valve brake |
||
Steering Gear | Power steering, hydraulic steering with power assistance | ||
Tire | Quantity | 6pcs with one spare tire | |
Specifications | 12.00R20 | ||
Fuel tank volume(L) | 400 L | ||
Transmission | Manual type, HW19710, 10 Forwards and 2 reverses | ||
Steering | Power steering, hydraulic steering with power assistance | ||
Cabin | It can accommodate three people, With Air conditioner | ||
Engine | Brand | SINOTRUK | |
Model | WD615.62 | ||
Fuel type | Diesel | ||
Displacement(ml) | 9726 ml | ||
Power(kw) | 88 kw | ||
Horsepower(HP) | 266 | ||
Cylinder number | 6 pcs | ||
Rated speed(rpm) | 2500 rpm | ||
Emission standard | Euro 2 | ||
Upper & Equipment | |||
Fuel tank | Capacity(cbm) | 5cbm, 5000Liters, 5M3, 5 Cubic Meters | |
Tank material | Aluminium alloy | ||
Compartment quantity(pcs) | 1 pcs | ||
Filling medium | Aviation kerosene, Jet A1 | ||
Piping system | Stainless steel | ||
Manhole | Quantity(pcs) | 2 pcs | |
Size(mm) | 500 mm | ||
Filter | International brand filter | ||
Remarks | Pls directly contact with us for more technical parameters |
1. Single row cab with sleeper, ellipse tank
2. side strap toolbox
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation
and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products
arriving at destination safely.
