60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel

60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel
60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel

Large Image :  60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel

Product Details:

Place of Origin: Suizhou, China
Brand Name: CLW
Certification: CLW9520cx
Model Number: ASME,CCC,SGS,BV

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: negotiable
Packaging Details: Naked Package,Bulk Ship,Roll-Roll
Delivery Time: 20~30 days after receiving deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Units/Month
Detailed Product Description
Size Option: 40m3,50m3,60m3,70m3,80m3,100m3,120m3 Materail: Carbon Steel Q345R
Filling Medium: Propane,butane Tank Diameter: DN2700mm
Design Pressure:: 1.77Mpa Level Gauge: China Brand Megnatic Type Or US Brand Rocheseter
Tank Valves: Cut-off Valve, Needle Valve, Safety Valve, Return Valve Etc.. LOGO: As Per Request
Service Time: 15 Years

Description:

Tank capacity: 5000 Liters , 10,000 liters, 15,000 Liters, 20,000 Liters, 25,000 Liters, 27,000 Liters, 30000 Liters, 35000 Liters, 50,000 liters, 80,000 liters, 100,000 liters,120,000 liters,150,000 liters,200,000 liters.


The liquefied petroleum gas storage tank (LPG Tank) is a pressure vessel for storing liquefied petroleum gas, and is mainly used in lpg gas storage stations and chemical enterprises.

  • Installation method: above ground and underground
  • Maximum allowable working pressure: 1.82MPa
  • Model specifications: 5m3 ~ 200m3
  • OEM available
  • Quality Assurance
  • Intelligent production mode
  • Leading the industry
  • Fast delivery
  • Every detail is strictly checked
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.


Product Description


1. Storage medium of lpg gas plant tank : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.

2. Tank sizes:5,000L, 20,000L, 30,000L, 40,000L, 50,000L, 60,000L, 80,000L, 100,000L, 120,000L etc.

3. Manufacturing standards of lpg gas plant tank : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008

4. Tank basic accessories included: valves, level meter, thermometer, pressure gauge etc.

5. Optional for lpg gas plant equipments as follows, lpg pump and motor,lpg compressor,volume flow meter,filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.

6. Maintenance-free operation with simple calibration and proof testing.

7. 20 years guarantee against manufacturing defects.

Parameter of 60000liters 30tons filling station gas tank
ITEM PARAMETER ITEM PARAMETER
Volume 60cbm Thickness of Shell 14mm
Tank Material Q345R Thickness of End plate 16mm
Overall Size 10962*2728*3318 mm Tank Net Weight 12750kg
Tank Diameter 2700mm Loading Capacity 23940kg
Design Pressure 1.71Mpa Gas Density 420kg/M3
Hydraulic Test Pressure 2.21Mpa Corrosion Allowance 1mm
Design Temperature -20ºC~60ºC Heat Treatment Bulk
Vapor Outlet DN50 Gas Outlet DN50
Life time 15 years
Accessories
Model Item Qty Junction surface
J41N-2.5-50 Stop Valve DN50 6 RF
J41N-2.5-25 Stop Valve DN25 2 RF
J41N-2.5-100 Stop Valve DN100 1 RF
J24W-320-DN6 J24W Needle Valve M20*1.5 1
HG21584-95 Magnetic plate level Gauge UZFAL-2.5RF-3040-0.5 1 RF
A42F-25-100 Safety Valve DN100 1 RF
Y-100T Pressure Gauge M20*1.5 1.5degree 0~4Mpa 1
WTQ-280 Thermometer M33*2 2.5 degree 1 -40ºC~60ºC



LPG filling station design:

60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel 0


60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel 1


60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel 2

Key words: 30tons LPG storage tank, LPG Tank,Cooking gas plant

60cbm 30ton LPG Storage Tank Filling Plant Propane Pressure Vessel 3

Our advantage

  • Certificate: ASME, ISO, BV, SGS, CCC etc.
  • More than 30 independents workshops for different types of trucks
  • 1000 sets of equipment, 25 assemble lines.
  • 300 senior engineers and technicians and about 8000 staffs
  • 800kinds of trucks and semi-trailers with various functions
  • 20 years wholesale experience
  • Turnover 250 million and Export 20million annually
  • More than 100,000 trucks and semi-trailers annually.
  • Truck Sold to 90 countries
  • Long term cooperation with China leading chassis supplier DONGFENG,SINOTRUCK,FOTON,FAW,BEIBEN,ETC
  • We can handle production of bulk order water trucks of tender and government purchase in required time
