HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
Home ProductsFuel Delivery Truck

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine
Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

Large Image :  Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: ISO, CCC
Model Number: clw5252WYYGC

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Naked package shipped by bulk ship
Delivery Time: 30 days after received advance payments
Payment Terms: L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
Supply Ability: 300units/month
Detailed Product Description
Truck Brand: Sinotruk Howo Drive Model: 8x4, 12-wheeler Fuel Tanker Truck
Tank Volume: 25000liters, 25000L, 25cbm, 25m3 Fuel Tanker Truck Fuel Type: Diesel/gasoline/oil Fuel Tanker Truck
Condition: New Fuel Tanker Truck Transmission Type: 10 Speed Forward And 2-reverse
Horsepower: 371hp Tank Material: Carbon Steel, Q235 Carbon Steel/ Stainless Steel, Carbon Steel/stainess Steel/aluminum Alloy, Aluminum Alloy, Aluminum 5083
Product Name: Fuel Tanker Truck, Fuel Delivery Truck,Fuel Tank Truck,howo Fuel Truck Emission Standard: Euro2
Wheelbase: 1800+4625+1350 Specification: 11970*24960*3025mm
Hose Reel With Filling Gun: Optional, Length Can Be Longer As Per Request
High Light:

25m3 Oil Tanker Truck

,

Sinotruk HOWO Oil Tanker Truck

,

8x4 Fuel Delivery Truck

Oil tamker truck is mainly used or storage and transport oil, diesel, gasoline, kerosene, stainless steel fuel bowser etc.

Product advantages
1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc but welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equipped separators baffle to prevent surging of liquid towards bulk head.
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.

Specification

General Technical Parameters
Overall Dimension 11970*24960*3025(mm) Gross Vehicle Weight 36000(kg)
Curb Weight 11450(kg) Loading Weight 25000(kg)
Chassis Specification
Chassis Parameters Chassis Brand SINOTRUK
Cabin Row and half, right Hand Driving
Engine Power 371HP
Emission standard EURO2
Displacement 9726ml
Fuel type Diesel
Gearbox 10 Forward & 2 Reverse Gear
Front and Rear Axle load 9T/16T (8x4 Driving type)
Wheel Base 1800+4625+1350(mm)
Brake System Pneumatic
Steering Gear Power Assistant
Tire 12.00R20, 12 Pieces+one spare tire
Maximum speed 85(km/h)
Tank Body
Shape Monoblock Cylinder
Total Volume(m3) 25m3
Tanker Body Material 5-6mm carbon steel
Manhole Cover ∮500mm ,1 set with 1 breather valve
Bottom Valve 1 set
Discharging Valve 1 set ∮80mm discharging valve
Painting Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
Accessories One standard tool box

Reference photos

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine 0

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine 1

Key words: Fuel bowser truck, fuel tanker truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, diesel dispensing truck, oil delivery truck, Mobile Fuel Truck, oil loading truck, oil refuelling truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, fuel bowser, diesel dispensing truck.



It can be divided into many compartments to transport different medium, which will make your transportation easy and safe.


Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.


Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.


After Sales Service
Email & Phone call tracking for each truck on timely manners.

Shipment
Land transportation or Ship by bulk cargo ship, container, roro ship
