FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser

China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
China HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD certification
I'm Online Chat Now

FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser

FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser
FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser

Large Image :  FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser

Product Details:

Place of Origin: Suizhou,China
Brand Name: CLW
Certification: ISO, CCC
Model Number: clw5041WYJYC

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: 9250-19520 USD/UNIT
Packaging Details: Naked package shipped by bulk ship
Delivery Time: 15~20 days after received advance payments
Payment Terms: L/C, T/T, D/P, T/T, Western Union, MoneyGram, D/A
Supply Ability: 300units/month
Detailed Product Description
Truck Brand: Dongfeng/Howo/JAC/FAW Refueling Truck Drive Model: 4x2, 6x4, 8x4, 6*4, 4*2,8*4 Refueling Truck
Tank Volume: 5000liters,5000L,3000L,3000liters Refueling Truck Fuel Type: Diesel/gasoline/oil/Jet A Refueling Truck
Condition: New Refueling Truck Transmission Type: 5 Speed Forward And 1-reverse Refueling Truck
Horsepower: 82hp 120hp Refueling Truck Tank Material: Carbon Steel, Q235 Carbon Steel/ Stainless Steel, Carbon Steel/stainess Steel/aluminum Alloy, Aluminum Alloy Refueling Truck
Product Name: Refueling Truck,Oil Bowser Truck, Fuel Delivery Truck,Fuel Tank Truck,howo Fuel Truck Emission Standard: Euro2/3/4/5 Refueling Truck
Wheelbase: 3300mm Refueling Truck Color: As Per Your Request
High Light:

5000Liters Fuel Transportation Truck

,

FAW J6F Fuel Transportation Truck

,

CCC Dispenser Fuel Delivery Truck

FAW J6F 5000 Liters Fuel Transportaion Truck Corrosion Resistant Tank With Dispenser



Mobile Refueling Truck (also called fuel tank truck, fuel tanker truck, fuel oil delivery trucks, oil transport tanker truck, mobile refueling truck, oil fueling vehicles, oil bowser trucks, petrol/diesel carrying vehicles, fuel bowser truck, oil tank trailer, fuel tanker semi trailers, mobile oil tank trucks) is used to transport fuel,oil,diesel,gasoline,kerosene and so on.



1. Optional tank capacity: 3 - 35 m3 (3,000 - 35,000 liters) for Oil Bowser Truck
2. 30 - 60 m3 (30,000 - 60,000 liters) for oil fuel trailer
3. Optional truck brand of Oil Bowser Truck: DFAC, Dongfeng, JAC, JMC, HOWO, FAW, SHACMAN, FOTON, North Benz, HINO, etc.
4. Optional wheel drive of Oil Bowser Truck: 4x2, 4x4, 6x4, 6x6, 8x4, left hand drive or right hand drive


Product advantage:

1. Purpose of Mobile Refueling Truck : It used for vehicles refueling and mobile transporting Fuel/Petrol/Diesel, etc.

2. Optional for Refueling System of Mobile Refueling Truck : Oil pump, Hose reel with filling gun/Oil dispenser machine,flow meter

3. Tank shape of Mobile Refueling Truck : shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
5. Refueling machine of Mobile Refueling Truck : the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
6. Optional parts of Mobile Refueling Truck : reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.





Tank body:



Tank/chassis interface is designed to prevent damage to tank during off-road operation.
Tank has a minimum of 5000 gallon (19000 litters) effective capacity including suitable expansion space.
Tank consists of a single compartment containing a minimum of two anti-surge baffles.
Tank is constructed from aluminum suitable for diesel fuel, gasoline and water.
All tank filler openings and vents are protected against overturn damage.

To provide bottom loading capability, the tank is furnished with an automatic vent valve, a level sensor

controlled automatic flow control valve, and a dry break bottom loading adapter with check valve.

The system, including the automatic vent, is failsafe to prevent damage to the tank and components if

the bottom loading system malfunctions or is operated incorrectly.

Emergency shut-off controls for fuel loading and discharging operations are provided.

All parts, including pump, piping, hoses and nozzles, having contact with fluids are corrosion resistant

and compatible with diesel fuel, gasoline and water.

Upper tank access is provided by ladder, leading to a grating-type catwalk to manhole, both affixed to tank.



Reference pictures


FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 0


FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 1


FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 2



FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 3

Specification of 5000Liters Refueling truck
No. Item Unit Specification
1 Vehicle Name   FAW 5000liters fuel refueling truck
2 Drive type   4*2
3 Steering type   LHD with power steering
4 Gross Weight kg 7360
5 Payload kg 5000
6 Wheelbase mm 3560
7 Overall Dimension mm 5990*2000*2350
8 Tank material   carbon steel lined with plastic
9 Standard configuration   anti-wave plate, Hydraulic bulging head, two PP or aluminum or stainless steel or TFE gravity-discharge valve, one rear climbing ladder
10 Transport medium   Oil,hydrochloric acid,sulfuric acid etc.
12 Chassis Brand   FAW J6F
13 Engine Model   YC4D130-33
14 Displacement / Power ml/kw 2982/ 95KW/ 130HP
15 Emission Standard   Euro 2
16 Fuel Type   Diesel
17 Tyre specification   7.50R16
18 Performance

*pump

*Tank capacity:2-30m3 for oil fuel truck,30-60 m3 for oil fuel trailer

*Oil tank material: carbon steel,stainless steel , aluminum alloy material tank

*Truck brand: DFAC, Dongfeng, JAC, JMC, HOWO, FAW, SHACMAN, YUEJIN, FOTON etc.

*Drive model:4x2, 4x4, 6x4, 6x6, 8x4, left hand drive or right hand drive

*Engine Brand: Cummins,weichai,Yuchai etc.

*Right/Left hand drive, with A/C,double row.

*Emission Standard: Euro II/EuroIII/EuroIV/EuroV.



FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 4


FAQ



Q: Can I buy a sample of your product for testing?

A.Yes, that's fine. Our MOQ is 1set.



Q: What's about the payment?

A: 40% deposit by T/T before order,balanced by T/T before delivery.



Q: How about quality of your factory product ?

A: Our product quality is ahead of other manufacturers in the industry. We have advanced production equipment ,skilled workers and perfect mangement quality. So the quality is under control. Our products are certificated by ISO 9001:2008,CCC and BV, and many trucks passed SGS inspection .


Q: How do you gurantee the quality of the product?

A: Don't worry, my dear client. Any one of you is very important to us. So we will do inspect all of the goods before shipment. And we had joined the trade credit insurance system. If the product received has quality problems, Alibaba will return the advance payment back to you.

Q: Why do you choose us?

A: We are self-produced and self-selling manufacturer and we have more than 15 years of production experience, our products have been sold all over the world.

Q: What about your after-sale service?
A: We offer 1 year after-sale service. We can supply the spare parts at factory price all the time.



Q:Can we visit your factory before purchasing?
A: We welcome you to visit our factory any time and we will show you our production line .



FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 5

Factory of mobile refueling truck

FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 6

Different size and brands of mobile refueling truck

FAW J6F 5000 Liters Fuel Transportation Truck Corrosion Resistant Tank With Dispenser 7

Key word: 10000liters fuel truck,howo fuel truck,10tons fuel truck,10t oil truck,howo fuel truck,Fuel dispenser truck, Oil Dispenser Truck, Oil Refueling Truck, Oil Delivery Truck,20k liters fuel truck,20000liters fuel truck,shacman tanker truck,diesel dispensing truck,oil tanker lorry,fuel lorry,
