ISUZU 6000L Mobile Fuel Refueling Truck
Diesel & Gasoline On-Demand Fuel Delivery Solution
Product Overview
The ISUZU 6000-liter mobile fuel refueling truck is a compact and efficient solution for modern fuel distribution. Designed to combine fuel storage, dispensing, and intelligent control in one vehicle, it enables direct fuel delivery to vehicles and equipment at their operating location, reducing dependence on fixed fuel stations and improving operational efficiency.
The dual-compartment tank structure allows the truck to carry and dispense both diesel and gasoline in a single trip. This configuration supports flexible fuel supply for mixed fleets and high-frequency service scenarios, helping operators shorten refueling cycles and optimize daily fuel logistics.
Fuel System & Operation
The truck is equipped with sealed, compartmentalized fuel tanks designed to prevent leakage and cross-contamination. Two independent fuel dispensers support simultaneous refueling of two vehicles, making it suitable for fleet fueling, roadside assistance, and on-site operations.
High-precision flow meters ensure accurate fuel measurement for every transaction, while the dual oil pump system supports both fuel loading from depot storage and fuel discharge to ground tanks or equipment. All functions are controlled through a centralized operation panel, enabling stable and efficient one-person operation.
Safety, Control & Environmental Protection
The vehicle integrates multiple safety protections, including explosion-proof electrical components, emergency shutoff valves for each fuel compartment, and vapor recovery systems to reduce emissions during refueling. Smart electronic sealing systems help monitor unauthorized access, and the API discharging port ensures secure and regulated fuel transfer.
These features make the truck suitable for operation in urban environments, industrial zones, and sensitive working areas with strict safety requirements.
Functions & Application Scenarios
This mobile fuel refueling truck supports on-demand fuel delivery for private vehicles and commercial fleets, reducing downtime and eliminating unnecessary trips to fuel stations. It is also suitable for emergency fuel supply during power outages or disaster situations, as well as for off-grid operations such as construction sites, mining areas, and agricultural fields.
In addition, the vehicle is widely used for temporary fuel supply at outdoor events, film productions, exhibitions, and mobile facilities requiring reliable generator power.
Overall Advantages
By integrating multi-fuel transport, simultaneous dispensing, precise metering, and comprehensive safety protection, the ISUZU 6000L mobile fuel refueling truck provides a practical and scalable solution for fuel delivery operations. Its flexible deployment, efficient operation, and compliance-oriented design make it an ideal choice for modern mobile fueling services across different markets.
Technical Specifications
| Specification |
Details |
| Overall Dimension |
6800 x 2400 x 2550 mm |
| Gross Vehicle Weight |
11000 kg |
| Curb weight |
5500 kg |
| Loading Weight |
6510 kg |
| Wheel Base |
3815mm |
| Front overhang |
1110mm |
| Rear overhang |
2022mm |
| Front wheel track |
1680mm |
| Rear wheel track |
1650mm |
| Cabin |
2 or 3 Passenger Allowed, with A/C, central locking, electric windows and multi-function steering wheel |
| Engine |
Diesel Engine 4HK1-TCG61, Water Cooling, Four Stroke, 4 Cylinder in Line, Direct Injection |
| Horse Power/Emission |
190HP/Euro 6 |
| Gearbox |
Manual, MLD, 6 Forward & 1 Reverse Gear |
| Axle |
4000kg Front Axle, 7000kg Rear Axle |
| Max Driving Speed |
90 km/h |
| Tire |
235/75R17.5, 6 pieces with 1 spare tire |
| Tank Capacity |
6,000 Liters with 2 compartments |
| Tank Material |
Q235 carbon steel, 5mm thickness, color and design can be customized |
| External box structure |
Rear operation room equipped with aluminum alloy rolling shutter door and 2 pull straps |
| Manhole cover |
2 sets API manhole cover |
| Truck mounted dispenser |
Dispenser with receipt printer, 2 sets mounted in the rear operation room |
| Oil Filling System |
Bottom gravity discharge, Oil Flow Meter (1 Unit), Oil filling pump (1 Unit), Standard tool box (1 Unit) |
