12000L 60T LPG Gas Storage Tank For Liquid Petroleum Gas Filling Plant

Large Image : 12000L 60T LPG Gas Storage Tank For Liquid Petroleum Gas Filling Plant

Product Details:

Place of Origin:	Suizhou, China
Brand Name:	CLW
Certification:	CLW9520xs
Model Number:	ASME,CCC,SGS,BV

Payment & Shipping Terms:

Minimum Order Quantity:	1 Unit
Price:	negotiable
Packaging Details:	Naked Package,Bulk Ship,Roll-Roll
Delivery Time:	20~30 days after receiving deposit
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	500 Units/Month

Contact Now

Detailed Product Description

Size Option:	60tons,60mt,120cbm,120m3,120000Liters	Materail:	Carbon Steel Q345R
Filling Medium:	Propane,butane	Tank Diameter:	DN3400mm
Design Pressure::	1.77Mpa	Level Gauge:	China Brand Megnatic Type Or US Brand Rocheseter
Tank Valves:	Cut-off Valve, Needle Valve, Safety Valve, Return Valve Etc..	LPG Compressor:	Optional With Chinese Brand, US Brand
LPG Pump:	Optional With Chinese Brand, US Brand	Production Time:	35-45 Days
Service Time:	15 Years	LOGO:	As Per Request
Shipment:	Bulk Shipment	Painting:	Double Layer Painting
Special Treatment:	Waxing Before Shipment To Prevent Rust
Highlight:	60T LPG Gas Storage Tank , 12000L LPG Gas Storage Tank , DN3400mm lpg storage tank

60tons LPG Gas Tank 120,00L Liquid Petroleum Gas Filling Plant

Product Description

1. propane storage tank's storage medium: LPG, propane,Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc

2. Available propane storage tank capacity: 5m³~200m³,2ton~100tons

3. Manufacturing standards of propane storage tank: GB-150, ASME, U STAMP, CCC, ISO9001 : 2008

60tons LPG Gas Tank
Volume of Tank		120cbm
Filling Weight		47880 kg
Tank Weight		24960 kg
Thickness of Shell (mm)		18 mm
Thickness of End plate (mm)		20 mm
Tank Diameter (mm)		3400 mm
External Dimensions (mm) (length x width x height)		13820 x 3436X4026 mm
Material of Tank and Main Pressure Parts		Carbon Steel Q345R
Filling Medium		Liquefied Petroleum Gas ( Propane)
Design Pressure		1.77 MPa / 17.7Bar
Corrosion Allowance		1 mm
Medium Density		500 kg/ cbm
Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.
Main parts of LPG Tank
Item	Specification		Quantity
Discharge Pipe	DN80		1
Inflow Pipe	DN80		1
Gas phase balance pipes	DN50		2
Drain Hole	DN50		1
Manhole	DN450		1
Air-out Pipe	DN50		1
Safety Valve Pipe	DN80		2
Safety Accessories (Included in the quotation): Cut-off Valve, Needle Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge.
