Product Details:
Payment & Shipping Terms:
|
| Product Name: | HOWO Wrecker Recovery Rescue Tow Truck | Truck Brand: | Sinotruk HOWO, SHACMAN, FAW, FOTON, JAC Etc |
|---|---|---|---|
| Drive Model: | 4x2, 6 Wheels, 6 Wheeler | Drive Type: | Right Hand Drive, Or Left Hand Drive. |
| Max. Loading Weight: | 4000KG, 5000KG, 4 TONS, 5 TONS, | Equipment: | Hydraulic Pump, Oil Cylinder |
| Main Parts: | Boom, Hoisting, Winches, Landing Leg | Wire Rope: | 25 Meters |
| High Light: | 3 Tons Flatbed Towing Truck,LHD Flatbed Towing Truck,Sinotruk HOWO 4x2 Wrecker Tow Truck |
||
Sinotruk HOWO 4*2 3 tons Tow Truck Small Road Rescue Wrecker Flatbed Towing Truck
Product Description:
1. Purpose of 4ton flatbed tow truck: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of 4ton flatbed tow truc:howo,Dongfeng,Isuzu,JAC,JMC,Foton,Shacman.
3. Spare parts of 4ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. The customers can choose to install the crane.
1) 5Tons Wrecker Truck for Towing Broken Cars or Equipments.
2) Dongfeng Brand Chassis for Euro 2 or Euro 3 Emission
3) Spare parts of 5tons wrecker tow truck:
Specification:
| General Technical Specification | |||||
| Overall Dimension | 5995x2300x2350(mm) | ||||
| Gross Vehicle Weight | 4495 (Kg) | ||||
| Curb Weight | 3790(Kg) | ||||
| Chassis Specification | |||||
| Chassis Brand | Sinotruk Howo | ||||
| Drive model | 4*2 | ||||
| Cabin | Single, Left Hand Drive | ||||
| Engine | Model | 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | |||
| Power | 105KW/143HP | ||||
| Emission standard | EURO2 or 3 | ||||
| Displacement | 3856(ml) | ||||
| Fuel type | Diesel | ||||
| Gearbox | 6 Forwards & 1 Reverse, Power steering, hydraulic steering with power assistance | ||||
| Brake System | Pneumatic(Air break/exhaust brake) | ||||
| Wheel Base | 3280(mm) | ||||
| Front/Rear Axle Loading | 2500/4800(Kg) | ||||
| Approach/Departure Angle | 24/12(°) | ||||
| Tire | 7.00R16, 6pcs + 1 spare tire | ||||
| Max Driving Speed | 98(km/h) | ||||
| Superstructure Specification | |||||
| Platform Organ | Dimension | 4200*2320(mm) | |||
| Rear manual flip board length | 1200(mm) | ||||
| Material | Q235 carbon steel | ||||
| Max Loading capacity | 4000(kg) | ||||
| Winch | Quantity | 1 | |||
| Winch rating towing capacity | 4000(kg) | ||||
| Length of steel rope | 25(m) | ||||
| Speed of winch | 3.23~8 (m/min) | ||||
| Other parts | Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc. | ||||
| Options | Caution light, air condition,inlet valve. | ||||
