Product Details:
Payment & Shipping Terms:
|
| Filling Medium: | Cooking Gas, Propane, LPG, Gas, Butane | Gas Density: | 420kg/Cbm |
|---|---|---|---|
| Tanker Material: | Q345R, 16MnDR, Q370R, SA516Gr70, SA517, Etc. | Loading Capacity: | 30t, 30Ton, 30tons, 30mt, Etc. |
| Tank Size: | 60m3, 60cbm, 60000liters, 600000L | Overall Size (length X Width X Height): | 10962*2728*3318(mm) |
| Tank Diameter: | DN2700mm, Etc. | Tank Thickness: | Shell 14mm, Head 16mm. |
| Design Pressure: | 1.71Mpa/17.1Bar, 1.77Mpa/17.7Bar, 1.61Mpa/16.1Bar | Hydraulic Test Pressure: | 2.21MPa 22.1bar |
| Design Temperature: | -20℃~50℃ | Corrosion Allowance: | 1 Mm |
| Life Time: | 20 Years | Logo And Color: | As Per Customer's Requests |
| High Light: | GB150 Liquid Propane Gas Tank,30 Ton Liquid Propane Gas Tank,60000 Liter LPG Gas Storage Tank |
||
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc.
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
Product Specification
| 60CBM LPG Tank Specifications | ||||
| Volume of Tank | 60 CBM | |||
| Filling Weight | 33060 kg | |||
| Tank Weight | 12750 kg | |||
| Thickness of Shell (mm) | 14 mm | |||
| Thickness of Head (mm) | 16 mm | |||
| Tank Diameter | 2700 mm | |||
|
Overall Size |
10962*2728*3318(mm) | |||
| Material of Tank | Carbon Steel Q345R | |||
| Design Pressure | 1.77 MPa | |||
| Hydraulic Test Pressure | 2.22 Mpa | |||
| Design Temperature | -20℃~50℃ | |||
| Heat Treatment | Bulk | |||
| Corrosion Allowance | 1 mm | |||
| Medium Density | 580 kg/m³ | |||
| Vapor Outlet | DN50 | |||
| Gas Outlet | DN50 | |||
| Life Time | 15 years | |||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | ||||
| Standard Accessories of LPG Tank | ||||
| Model | Item | Qty | Junction Surface | |
| A42F-25-100 | Safety Valve DN100 | 1 | RF | |
| J41N-2.5-50 | Stop Valve DN50 | 6 | RF | |
| J41N-2.5-25 | Stop Valve DN25 | 2 | RF | |
| J41N-2.5-100 | Stop Valve DN100 | 1 | RF | |
| J24W-320-DN6 | J24W Needle Valve M20*1.5 | 1 | / | |
| HG21584-95 | Magnetic plate level Gauge UZFAL-2.5RF-3040-0.5 | 1 | RF | |
| Y-100T | Pressure Gauge M20*1.5 1.5degree 0~4Mpa | 1 | / | |
| WTQ-280 | Thermometer M33*2 2.5 degree | 1 | -40℃~60℃ | |
We supply customized drawing for every storage tank
| Nozzle data | |||||
| Characters | Size | Pressure(MPa) | Connect | Junction surface | Purpose |
| a | DN50 | 25 | HG20592-WN | RF | Drain outlet |
| b | DN50 | 25 | HG20592-WN | RF | Liquid phase outlet |
| c1-2 | DN50 | 25 | HG20592-WN | RF | Gaseous phase balanced outlet |
| d | DN50 | 25 | HG20592-WN | RF | Liquid inlet |
| e | M33*2 | Screw-thread | Thermometer connection | ||
| f1-2 | DN25 | 25 | HG20592-WN | RF | Lever gauge connection |
| g | M20*1.5 | Screw-thread | Pressure Gage | ||
| h | DN100 | 25 | HG20592-WN | RF | Safety valve connection |
| i | DN50 | 25 | HG20592-WN | RF | Emptying mouth |
| j | DN450 | 25 | HG20592-WN | FM | Manhole |
Structure Diagram of LPG Storage Tank
After-sales Service
1. Provide English operation manual and Instruction videos.
2. One year free warranty for major 3 components: engine, gearbox, axles; One set of easily worn spare parts of truck chassis for free; Spare parts supplied at factory price whenever needed.
3. Aftersales service whenever needed. Our engineers will go to customer's country to assist the installation and operation if order QTY.is more than 10 units. Contact Lea For More Details: +86 155 2791 1810.
FAQ
Q1: What kinds of LPG storage tank I can order from your company?
A: We can supply different sizes LPG storage tank as client's request. Basically speaking, we can supply 5CBM to 200CBM type. Pls contact with us for more technical details and discussion.
Q2: What is your production standard of LPG storage tank?
A: Transportable Pressure Vessel Safety Technology Supervisory Regulations and GB150.1~4-2011Transportable Pressure Vessel Safety Technology Supervisory Regulations and GB150.1~4-2011
Q3: Can we adopts International brand parts or accessories for LPG storage tank?
A: Sure, we already cooperated with many international brand suppliers.
Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to Wuhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
